Marantz SR-14 - Page 50

76
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C711
ELECT. 220µF M 100V RA2 OA22710020
C714
C715 4822 124 11533 ELECT. 1µF M 100V RA2 OA10510020
C716 4822 124 11533 ELECT. 1µF M 100V RA2 OA10510020
C717 4822 123 30088 MICA 10pF ±0.5pF 250V FE DF31100520
C718 4822 123 30088 MICA 10pF ±0.5pF 250V FE DF31100520
C719 ELECT. 4.7µF M 100V RE3 EA47510010
C720 ELECT. 4.7µF M 100V EA47510010
C727
9965 000 00438 FILM CAP 120pF ±5% 100V OF15121540
C730
CT01 4822 124 90058 ELECT. 47µF M 25V ARA OA47602550
CT03 FILM CAP 470pF ±5% 100V OF15471540
CT05 FILM CAP 470pF ±5% 100V OF15471540
CT07 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CT11 ELECT. 220µF M 100V RA2 OA22710020
CT13 ELECT. 220µF M 100V RA2 OA22710020
CT15 4822 124 11533 ELECT. 1µF M 100V RA2 OA10510020
CT17 4822 123 30088 MICA 10pF ±0.5pF 250V FE DF31100520
CT19 ELECT. 4.7µF M 100V EA47510010
CT27 9965 000 00438 FILM CAP 120pF ±5% 100V OF15121540
CT29 9965 000 00438 FILM CAP 120pF ±5% 100V OF15121540
P704-CAPACITORS (COMMON)
PLASTIC FILM CAPACITOR
±5% 50V :
C721-C726 CT21 CT23 CT25
P704-RESISTORS
R707
1.5kΩ ±5% 1/6W GG05152160
R710
R715 4822 100 12159 TRIM. 100kΩ RH0638CJ4R RA01040780
R716 4822 100 12159 TRIM. 100kΩ RH0638CJ4R RA01040780
R725
4822 052 10569 56Ω 1/6W GG05560160
R736
R743 4822 100 20681 TRIM. 2.2kΩ RH0638CJ3R RA02220780
R744 4822 100 20681 TRIM. 2.2kΩ RH0638CJ3R RA02220780
R749
4822 052 10109 10Ω ±5% 1/4W GG05100140
R752
R753
4822 052 10101 100Ω 1/6W GG05101160
R756
R757
JUMPER 75060501P0
R760
R761 4822 052 10102 1kΩ ±5% 1/6W GG05102160
R762 4822 052 10102 1kΩ ±5% 1/6W GG05102160
R763
4822 052 10229 22Ω 1/6W GG05220160
R766
R767 4822 116 60319 FUSIBLE 220Ω ±5% 1/2W NH05221120
R768 4822 116 60319 FUSIBLE 220Ω ±5% 1/2W NH05221120
R769
4822 052 10228 2.2Ω ±5% 1/6W GG05022160
R772
R773 9965 000 01764 0.10Ω K 5W X2 RGC55 W/TP BZ10102020
R774 9965 000 01764 0.10Ω K 5W X2 RGC55 W/TP BZ10102020
R775 4822 052 10102 1kΩ 1/6W GG05102160
R776 4822 052 10102 1kΩ 1/6W GG05102160
R777 4822 050 22202 2.2kΩ ±5% 1/6W GG05222160
R778 4822 050 22202 2.2kΩ ±5% 1/6W GG05222160
R783 4822 116 83929 220Ω ±5% 1/4W GG05221140
R784 4822 116 83929 220Ω ±5% 1/4W GG05221140
R785 4822 053 10109 10Ω 1W GA05100010
R786 4822 053 10109 10Ω 1W GA05100010
RT07 1.5kΩ ±5% 1/6W GG05152160
RT09 1.5kΩ ±5% 1/6W GG05152160
RT15 4822 100 12159 TRIM. 100kΩ RH0638CJ4R RA01040780
RT25 4822 052 10561 560Ω 1/6W GG05561160
RT27 4822 052 10561 560Ω 1/6W GG05561160
RT29 4822 052 10561 560Ω 1/6W GG05561160
RT31 4822 052 10561 560Ω 1/6W GG05561160
RT33 4822 052 10569 56Ω 1/6W GG05560160
RT35 4822 052 10569 56Ω 1/6W GG05560160
RT43 4822 100 20681 TRIM. 2.2kΩ RH0638CJ3R RA02220780
RT49 4822 052 10109 10Ω ±5% 1/4W GG05100140
RT51 4822 052 10109 10Ω ±5% 1/4W GG05100140
RT53 4822 052 10101 100Ω 1/6W GG05101160
RT55 4822 052 10101 100Ω 1/6W GG05101160
RT57 JUMPER 75060501P0
RT59 JUMPER 75060501P0
RT61 4822 052 10102 1kΩ ±5% 1/6W GG05102160
RT63 4822 052 10229 22Ω 1/6W GG05220160
RT65 4822 052 10229 22Ω 1/6W GG05220160
RT67 4822 116 60319 FUSIBLE 220Ω ±5% 1/2W NH05221120
RT69 4822 052 10228 2.2Ω ±5% 1/6W GG05022160
RT71 4822 052 10228 2.2Ω ±5% 1/6W GG05022160
RT73 9965 000 01764 0.10Ω K 5W X2 RGC55 W/TP BZ10102020
RT75 4822 052 10102 1kΩ 1/6W GG05102160
RT77 4822 050 22202 2.2kΩ ±5% 1/6W GG05222160
RT83 4822 116 83929 220Ω ±5% 1/4W GG05221140
RT85 4822 053 10109 10Ω 1W GA05100010
P704-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R701-R706
R711-R714 R717-R724
R737-R742 R745-R748
R779-R782 R787-R790 RT01
RT03 RT05 RT11 RT13 RT17
RT19 RT21 RT23 RT37 RT39
RT41 RT45 RT47 RT79 RT81
RT87 RT89
P704-SEMICONDUCTORS
D701
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
D704 30V 0.1A
JUMPER 75060501P0
D712
D713
4822 130 80837 DIODE HSS81 HD20027010
D716
D717
4822 130 80317 ZENER DIODE 5.1V HD30511000
D720 RD5.1JB2 MTZJ5.1B
D721 4822 130 80837 DIODE HSS81 HD20027010
D722 4822 130 80837 DIODE HSS81 HD20027010
DT01 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT03 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DT05 JUMPER 75060501P0
DT07 JUMPER 75060501P0
DT09 JUMPER 75060501P0
DT11 JUMPER 75060501P0
DT13 4822 130 80837 DIODE HSS81 HD20027010
DT15 4822 130 80837 DIODE HSS81 HD20027010
DT17 4822 130 80317 ZENER DIODE 5.1V
RD5.1JB2 MTZJ5.1B
HD30511000
DT19 4822 130 80317 ZENER DIODE 5.1V
RD5.1JB2 MTZJ5.1B
HD30511000
DT21 4822 130 80837 DIODE HSS81 HD20027010
