Marantz SR-14 - Page 53

79
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P774-PO-AMP.TR-BLOCK
3CH CIRCUIT BOARD
P774-SEMICONDUCTORS
D799 4822 116 21235 VARISTOR
PTH9M04BE222TS2F333
HP00004230
Q715 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
Q716 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
Q725 9965 000 01762 TRS. 2SC2922 O OR Y HT329222A0
Q726 9965 000 01762 TRS. 2SC2922 O OR Y HT329222A0
Q727 9965 000 01763 TRS. 2SA1216 O OR Y HT112162A0
Q728 9965 000 01763 TRS. 2SA1216 O OR Y HT112162A0
QT15 4822 130 60117 TRS. 2SC3419 Y HT334191Y0
QT25 9965 000 01762 TRS. 2SC2922 O OR Y HT329222A0
QT27 9965 000 01763 TRS. 2SA1216 O OR Y HT112162A0
P804-POWER SUPPLY ±15V
CIRCUIT BOARD
P804-CAPACITORS
C801 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C802 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C803 4822 124 81133 ELECT. 4700µF 25V OA47802520
C804 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C805 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C806 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C807 4822 124 81133 ELECT. 4700µF 25V OA47802520
C808 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C817 5322 124 21731 ELECT. 10µF M 50V OA10605020
C818 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
P804-RESISTORS
R801 JUMPER 75060501P0
R802 JUMPER 75060501P0
R813 100
Ω
±5% 1/6W GD05101160
P804-SEMICONDUCTORS
D801 4822 130 83067 DIODE D3SB 20 V=200V
IO=3.0A
HE20020290
D802 4822 130 82421 DIODE 1D3 1A 200V HD20002710
D807 4822 130 82421 DIODE 1D3 1A 200V HD20002710
Q801 4822 209 70084 IC NJM7812FA +12V 1A HC38912090
Q806 4822 130 11605 TRS. 2SD1415 HT41415100
P804-MISCELLANEOUS
F801 /K,/N,/S 4822 117 10158 1
Ω
±5% 1/4W GG05010140
F801 /U FUSE T2A 250V TR5 NO.19374 FS20200210
F802 /K,/N,/S 4822 117 10158 1
Ω
±5% 1/4W GG05010140
F802 /U FUSE T2A 250V TR5 NO 19374 FS20200210
P854- MAIN+B
CIRCUIT BOARD
P854-CAPACITORS
C851 4822 122 30043 CER. 0.01µF +80%-20% E 500V DK18103560
C852 4822 126 12453 CER. 0.01µF +80%-20% E 500V DK18103560
C853 9965 000 01773 ELECT. 56000µF 71V X2 EI56907120
C854 4822 126 12453 CER. 0.01µF +80%-20% E 500V DK18103560
C855 /K,/N,/S 4822 121 43363 FILM 0.22µF ±20% ECQ-U
250V AC UL CSA VDE
DF17224800
C857 4822 124 40763 ELECT. 2.2µF M 50V RA-2 OA22505020
P854-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R851-R854
P854-SEMICONDUCTORS
D851 9965 000 01578 DIODE D25XB60 BRIDGE HE20029290
D853 4822 130 82421 DIODE 1D3 HD20002710
D854 4822 130 82421 DIODE 1D3 HD20002710
PB04-PRIMARY
CIRCUIT BOARD [U] VERSION
PB04-CAPACITORS
CB01 /U 4822 122 33276 CER. 0.01µF ±20% DE7150 F
SPARK KILLER
DK17103840
CB02 /U 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CB03 /U 4822 122 33276 CER. 0.01µF ±20% DE7150 F
SPARK KILLER
DK17103840
PB04-RESISTORS
RB01 /U 2.2M
Ω
±10% 1/2W FOR UL RC10225820
RB02 /U 9965 000 01761 ROTOR 2.2
Ω
7W
W/TEMP.FUSE
NQ15022070
RB05 /U 9965 000 01761 ROTOR 2.2
Ω
7W
W/TEMP.FUSE
NQ15022070
PB04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RB03 RB04
PB04-SEMICONDUCTORS
DB01 /U 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB02 /U 4822 130 82421 DIODE 1D3 1A 200V HD20002710
QB01 /U 4822 130 42682 DIG.TRS.
DTA144ES UN4113 47k 47k
BA10002000
QB02 /U 4822 130 60117 TRS. 2SC3419 O OR Y
40V 0.8A PC=1.2W 5W
HT334192A0
PB04-MISCELLANEOUS
FB01 /U FUSE 12A 250V UL CSA MITI
NO.314
FS11200440
FB02 /U FUSE 630mA 250V UL CSA
FBM
FS10063360
JB03 /U JACK 2P AC OUTLET
CCT1304-0212
YJ04002040
LB02 /U 4822 280 80773 RELAY VS24MB-NR TV-8
SEMKO LISTED
LY10240240
LB03 /U 4822 280 80773 RELAY VS24MB-NR TV-8
SEMKO LISTED
LY10240240
PB54-PRIMARY CIRCUIT
BOARD [/K, /N, /S] VERSION
PB54-CAPACITORS
CB51 /K,/N,/S 4822 122 33276 CER. 0.01µF ±20% DE7150 F
SPARK KILLER
DK17103840
CB52 /K,/N,/S 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CB53 /K,/N,/S 4822 122 33276 CER. 0.01µF ±20% DE7150 F
SPARK KILLER
DK17103840
PB54-RESISTORS
RB52 /K,/N,/S 9965 000 01761 ROTOR 2.2
Ω
7W
W/TEMP FUSE
NQ15022070
RB55 /K,/N,/S 9965 000 01761 ROTOR 2.2
Ω
7W
W/TEMP.FUSE
NQ15022070
PB54-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RB53 RB54
PB54-SEMICONDUCTORS
DB51 /K,/N,/S 4822 130 82421 DIODE 1D3 1A 200V HD20002710
DB52 /K,/N,/S 4822 130 82421 DIODE 1D3 1A 200V HD20002710
QB51 /K,/N,/S 4822 130 42682 DIG.TRS.
DTA144ES UN4113 47k 47k
BA10002000
QB52 /K,/N,/S 4822 130 60117 TRS. 2SC3419 O OR Y
40V 0.8A PC=1.2W
HT334192A0
