PB54-MISCELLANEOUS
FB51 /K,/N,/S 4822 070 36302 FUSE T6.3A 250V BS LISTED FS10630850
FB52 /K,/N,/S 4822 070 32001 FUSE T200mA 250V
BS LISTED
FS10020850
LB52 /K,/N,/S 4822 280 80773 RELAY VS24MB-NR TV-8
SEMKO LISTED
LY10240240
LB53 /K,/N,/S 4822 280 80773 RELAY VS24MB-NR TV-8
SEMKO LISTED
LY10240240
PB74- POWER SW
CIRCUIT BOARD
CB71 4822 122 33276 CER. 0.01µF ±20% DE7150 F
SPARK KILLER
DK17103840
SB71 9965 000 01777 PUSH SWITCH SDDLB1
POWER TV-5
SP01012460
PL04-CVBS VIDEO
SELECTOR CIRCUIT BOARD
PL04-CAPACITORS
CL01 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL02 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL03 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL04 JUMPER 75060501P0
CL05
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL09
CL10 JUMPER 75060501P0
CL11
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL23
CL24 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CL25
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL31
CL32 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CL33 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CL34 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL35 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CL36 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL37 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CL38 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL39 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL40 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL41 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CL42 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL43 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CL44 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CL46 /K,/N,/S 4822 126 10362 CER. 22pF ±5% DA15220110
CL47 /K,/N,/S 4822 126 11553 CER. 15pF ±5% DA15150120
CL48 /U 4822 122 33792 CER. 10pF ±5% DA15100120
CL49 4822 126 11591 CER. 24pF ±5% CH 50V BLK DD15240300
CL50 4822 126 10362 CER. 22pF ±5% DA15220110
CL52 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL53 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CL54 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CL55 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL56 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL57 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL58 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL59 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CL60 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL61 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CL62 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL63 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL64 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CL65 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CL66 JUMPER 75060501P0
CL67 /U CER. 22pF ±5% DA15220110
CL68 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL69 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL70 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL71
JUMPER 75060501P0
CL74
CL75 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL79 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CL80 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CL81 5322 124 21731 ELECT. 10 UV M 50V RA-2 OA10605020
CL82 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL83 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL84 4822 125 50384 TRIM. 20pF VCT51E CT12000200
CL86 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX84 4822 124 22277 ELECT. 470µF M 16V OA47701620
PL04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CL51 CL76 CL77
CL87-CL97[/N,/S]
PLASTIC FILM CAPACITOR
±5% 50V : CL78
PL04-RESISTORS
RL01 4822 111 41355 75
Ω
±5% 1/6W GD05750160
RL03 4822 111 41355 75
Ω
±5% 1/6W GD05750160
RL05 4822 111 41355 75
Ω
±5% 1/6W GD05750160
RL07 4822 111 41355 75
Ω
±5% 1/6W GD05750160
RL09 4822 111 41355 75
Ω
±5% 1/6W GD05750160
RV51 4822 050 21021 100
Ω
±5% 1/2W GG05101120
PL04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RL02 RL04 RL06
RL08 RL10-RL15 RL18-RL26
RL28-RL43 RV52 RV53
PL04-SEMICONDUCTORS
DL07 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DV01 4822 130 82421 DIODE 1D3 HD20002710
DV02 4822 130 82421 DIODE 1D3 HD20002710
DV03 4822 130 82421 DIODE 1D3 HD20002710
DV51 4822 130 82421 DIODE 1D3 HD20002710
DV52 4822 130 82421 DIODE 1D3 HD20002710
DV53 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QL01 9965 000 01371 IC MM1140XF HC10083550
QL02 4822 209 32928 IC BA7612N HC10201210
QL03 9965 000 01372 IC BA7649A G-1 VIDEO SW HC10179210
QL04 4822 209 31527 IC BA7613N HC10202210
QL05 9965 000 01372 IC BA7649A G-1 VIDEO SW HC10179210
QL06 4822 209 31527 IC BA7613N HC10202210
QL07 4822 209 16846 IC NJU3718L HC10171090
QL08 4822 209 32246 IC NJM2244
3IN SW 75
Ω
DRIVER
HC10119090
QL09 4822 209 15524 IC OSD LC74781 HC10377030
QL10 /K,/N,/S 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QL11 /K,/N,/S 4822 130 61189 DIG.TRS.
DTC114TS UN4215 10k
BA20004000
QL12 /K,/N,/S 4822 130 61189 DIG.TRS.
DTC114TS UN4215 10k
BA20004000
QL14 4822 209 32246 IC NJM2244
3IN SW 75
Ω
DRIVER
HC10119090
QL15 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
