POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QL16 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QL17 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
QL18 5322 209 71773 IC TC74HC132AP HC713205D0
QL19 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
QV51 4822 130 61227 DIG.TRS. DTA114ES ETC BA10001000
QV52 4822 130 63634 TRS. 2SA1837 Q Y HT118372A0
PL04-MISCELLANEOUS
JL01
4822 265 31299 TERMINAL 3P RCA PIN JACK YT02030340
JL03 YELLOW X 3 AU
JL04 4822 265 10729 TERMINAL YKC21-3740 YT02080130
JL05 4822 290 81598 TERMINAL 2P RCA JACK
YKC21-3255 GOLD
YT02021130
JL06 4822 290 81638 TERMINAL 14X14 RA 1L1P BL YT02010790
LL01 4822 157 62922 CHOKE COIL 33µH J LC13333800
LL02 4822 242 73843 EMI FILTER DSS306-91-F-223Z FM12223010
LL03
JUMPER 75060501P0
LL08
LV01 9965 000 01576 RELAY MR82-24USR LY20240480
LV02 9965 000 01576 RELAY MR82-24USR LY20240480
LV03 9965 000 01576 RELAY MR82-24USR LY20240480
XL01 /K,/N,/S 4822 242 73903 CRYSTAL AT49 17.7MHz JX17001260
XL02 4822 242 80288 CRYSTAL AT49 14.31818MHz JX14001260
PL74-AUX INPUT
CIRCUIT BOARD
PL74-CAPACITORS
CL75 /N,/S 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
CL76 /N,/S 4822 126 11568 CER. CHIP 470pF ±10% DK96471300
CL77 /N,/S 4822 122 33777 CER. CHIP 47pF ±5% DD95470300
CL78 /N,/S 4822 122 33777 CER. CHIP 47pF ±5% DD95470300
CL79
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CL82
CL83 4822 124 11947 ELECT. BP 10µF 16V EQ10601630
CL84 0
Ω
1/4W GD05000140
CL88 0
Ω
1/4W GD05000140
CL89 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CL90 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CL91
0
Ω
1/4W GD05000140
CL98
PL74-RESISTORS
RL75 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
RL76 4822 051 30102 CHIP 1k
Ω
±5% 1/16W NN05102610
RL77 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RL78 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RL79
4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RL82
RL83 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RL84 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RL85 4822 051 30759 CHIP 75
Ω
±5% 1/16W NN05750610
RL86 4822 051 30759 CHIP 75
Ω
±5% 1/16W NN05750610
RL88 4822 051 30759 CHIP 75
Ω
±5% 1/16W NN05750610
PL74-SEMICONDUCTORS
QL75 4822 209 71451 IC NJM4558M Y HC10011090
PL74-MISCELLANEOUS
JL75 9965 000 01347 TERMINAL RCA JACK 3P &
S-TERMINAL AUX
BY04040030
PM01 HDAM CIRCUIT BOARD
PM01-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RM01-RM06
PM01-SEMICONDUCTORS
DM01
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
DM05 30V 0.1A
QM01 4822 130 42839 F.E.T. FET 2SK369BL HF203691B0
QM02 4822 130 42839 F.E.T. FET 2SK369BL HF203691B0
QM03 4822 130 43233 TRS. 2SC2240 HT322402A0
QM04 4822 130 42949 TRS. 2SA970 HT109702A0
QM05 4822 130 42949 TRS. 2SA970 HT109702A0
QM06 4822 130 43233 TRS. 2SC2240 HT322402A0
PM04- HDAM CIRCUIT BOARD
PM04-CAPACITORS
CM21 JUMPER 75060501P0
CM22 JUMPER 75060501P0
CM25 4822 126 14166 FILM 330pF 100V PP OF15331540
CM26 4822 126 14166 FILM 330pF 100V PP OF15331540
CM27 9965 000 01344 FILM 100pF ±5% 100V OF15101540
CM28 9965 000 01344 FILM 100pF ±5% 100V OF15101540
CM29 ELECT. 47µF M 16V ARS OA47601640
CM30 ELECT. 47µF M 16V ARS OA47601640
CM31 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
CM32 4822 124 90354 ELECT. 100µF M 16V RA-2 OA10701620
PM04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :
RM21-RM24 RM27-RM40
PM04-SEMICONDUCTORS
DM21 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DM22 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
QM21 4822 130 42949 TRS. 2SA970 HT109702A0
QM22 4822 130 42949 TRS. 2SA970 HT109702A0
QM23 4822 130 43233 TRS. 2SC2240 HT322402A0
QM24 4822 130 43233 TRS. 2SC2240 HT322402A0
QM25 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QM26 4822 130 43283 TRS. 2SC2705 O OR Y HT327052A0
QM27 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
QM28 4822 130 42999 TRS. 2SA1145 O OR Y HT111452A0
QM29 UNIT & H-IC NEW HDAM KH269J1010
QM30 UNIT & H-IC NEW HDAM KH269J1010
PS04-A-FUNC. PRE SUPPLY
CIRCUIT BOARD
PS04-CAPACITORS
C809 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C810 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C811 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C812 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C813 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C814 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C815 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C816 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C819 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C820 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C821 9965 000 01351 ELECT. 13000µF M 16V RE3 EA13901670
C824 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C825 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
C826 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
C827 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
