Marantz SR-14 - Page 58

84
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QU03
4822 130 41947 TRS. 2SC2458 2SC1740S HT30001000
QU06 2SC3199 ETC.
QU07 4822 130 63211 DIG.TRS.
DTA114TS UN4115 10k
BA10004000
PU04-MISCELLANEOUS
SU01
9965 000 00373 PUSH SWITCH SP01013370
SU26 EVQ11L05R 160GF
SU32 9965 000 01348 ROTARY SWITCH ROTARY
ENCODER FOR MASTER
SR02010070
SU33 9965 000 01349 ROTARY SWITCH ROTARY
ENCODER FOR INP. SELECT
SR02010080
VU01 9965 000 01350 DISPLAY UNIT SVA-12MM20
FL DISPLAY
HQ31201920
PU74-STANDBY LED
CIRCUIT BOARD
CU71 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
DU71 4822 130 11569 L.E.D. HLMF-K200 RED HI10005340
RU71 680
Ω
±5% 1/16W GD05681160
PU84-IR SENSOR
CIRCUIT BOARD
CU81 4822 122 40588 CER. 0.022µF ±20% DA17223110
CU82 4822 124 80087 ELECT. 220µF 6.3V EJ22700610
QU81 4822 209 16157 PHOTO UNIT PNA4655M00XB
IR SENSOR
HW10005020
PU94-GYRO ENCODER
CIRCUIT BOARD
CU91 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
RU91 330
Ω
±5% 1/16W GD05331160
QU91 4822 130 11143 PHOTO UNIT GP1A06 2PHASE
PHOTO INTERRUPTER
HW10033320
PW04-HEADPHONE
CIRCUIT BOARD
CW01 4822 122 40586 CER. 0.01UF DA17103110
CW02 4822 122 40586 CER. 0.01UF DA17103110
CW03 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CW04 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
JW01 GOLD 4822 265 11525 H.P. JACK HLJ2307-01-3163 YJ01004330
PY04-µ-COM
CIRCUIT BOARD
PY04-CAPACITORS
CY01 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY02 4822 124 23056 ELECT. 47µF 10V EJ47601010
CY04 5322 126 11583 CER. CHIP 0.01µF ±10% B 25V DK96103200
CY07 4822 126 13303 CER. CHIP 1µF 10V F DK98105200
CY08 5322 126 11583 CER. CHIP 0.01µF ±10% B 25V DK96103200
CY09 5322 126 11583 CER. CHIP 0.01µF ±10% B 25V DK96103200
CY10 5322 126 11583 CER. CHIP 0.01µF ±10% B 25V DK96103200
CY11 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY12 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY13 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY19 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY25 5322 126 11578 CER. CHIP 1000 ±10% B 50V DK96102300
CY26 4822 126 11687 CER. CHIP 0.1µF +80%-20% DK98104200
CY30 4822 124 11879 BIG ELECT. 1F 5.5V
DB-5R5D105
EX10500530
PY04-RESISTORS
RY01 4822 051 30479 CHIP 47
Ω
±5% 1/16W NN05470610
RY02 4822 116 83819 CHIP 18k
Ω
±5% 1/16W NN05183610
RY03 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RY04 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RY05 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RY06
4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
RY11
RY12 4822 051 30105 CHIP 1M
Ω
±5% 1/16W NN05105610
RY13 4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
RY14 /K,/S 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RY15 /N,/U 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY16 /K,/N,/S 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RY17 /U 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY19 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY21 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY22 /N,/S 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RY23 /K 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY23 /U 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY24 4822 051 30472 CHIP 4.7k
Ω
±5% 1/16W NN05472610
RY25 4822 051 30472 CHIP 4.7k
Ω
±5% 1/16W NN05472610
RY27
4822 051 30472 CHIP 4.7k
Ω
±5% 1/16W NN05472610
RY31
RY32 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY33 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY34 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY35 4822 051 30221 CHIP 220
Ω
±5% 1/16W NN05221610
RY36 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY37 4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY38
4822 051 30221 CHIP 220
Ω
±5% 1/16W NN05221610
RY45
RY46
4822 116 82487 CHIP 0
Ω
±5% 1/16W NN05000610
RY56
RY57 4822 117 12925 CHIP 47k
Ω
±5% 1/16W NN05473610
RY58 4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
RY59 4822 051 30683 CHIP 68k
Ω
±5% 1/16W NN05683610
RY60 4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
RY64 4822 051 30273 CHIP 27k
Ω
±5% 1/16W NN05273610
RY65 4822 051 30221 CHIP 220
Ω
±5% 1/16W NN05221610
RY66 4822 051 30221 CHIP 220
Ω
±5% 1/16W NN05221610
RY67 4822 051 30103 CHIP 10k
Ω
±5% 1/16W NN05103610
RY68 4822 051 30273 CHIP 27k
Ω
±5% 1/16W NN05273610
PY04-SEMICONDUCTORS
DY01
4822 130 83715 CHIP DIODE 1SS301 DAN202U HZ21005000
DY04
QY01 9965 000 01345 MICROPROCESSOR
TMP93CW40DF MAIN CPU
HU300JT00F
QY02 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QY03 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY04 4822 130 42594 DIG.TRS.
DTC144ES UN4213 47k 47k
BA20002000
QY05 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY06 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY07 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
QY08 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY09 4822 130 60588 DIG.TRS.
DTC114ES UN4211 10k 10k
BA20001000
QY10 4822 130 61227 DIG.TRS.
DTA114ES UN4111 10k 10k
BA10001000
QY11 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
