85
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
QY12 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QY13 4822 130 60588 DIG.TRS.
DTC114ES UN4211 KRC102M
BA20001000
QY14 4822 130 61227 DIG.TRS. DTA114ES UN4111
KRA102M-AT
BA10001000
QY15 4822 209 12845 IC S-80730SN-DT-X RESET HC10054530
PY04-MISCELLANEOUS
WY01 JUMPER LEAD SMCD-33X100-
BDX10-P1 25-S6
YU33100500
XY01 9965 000 01346 SERAMIC VIB.
CST20.00MXW0H1 20MHz
FQ02005030
PY64-CONNECT-1
CIRCUIT BOARD
PY64-CAPACITORS
CY61 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CY62 5322 124 21731 ELECT. 10µF M 50V OA10605020
DY61 4822 130 82421 DIODE 1D3 1A 200V HD20002710
LY61 9965 000 01353 RELAY FTR-F1AA024T LY20240460
QY61 4822 130 60117 TRS. 2SC3419 HT334192A0
RY61 4822 115 90167 FUSE 100
Ω
G 1/4W NF02101140
RY62 10k
Ω
±5% 1/16W GD05103160
RY63 10k
Ω
±5% 1/16W GD05103160
PZ04-S-VIDEO SELECTOR
CIRCUIT BOARD
PZ04-CAPACITORS
CX01 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX02 4822 122 31349 CER. 68pF ±5% 50V DD15680300
CX03 /K,/N,/S 5322 122 32143 CER. 22pF ±5% 50V DD15220300
CX04 4822 124 22275 ELECT. 47µF M 10V RA-2 OA47601020
CX05 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CX06 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CX07 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX08 /U 4822 126 10362 CER. 22pF ±5% 50V DA15220110
CX09 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX10 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX11 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX12 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CX13 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX14 5322 124 21731 ELECT. 10µF M 16V RA-2 OA10605020
CX15 5322 124 21731 ELECT. 10µF M 16V RA-2 OA10605020
CX16
4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CX19
CX20 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CX21 FILM 4700pF DF15472350
CX22 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CX23 4822 125 50384 TRIM. 20pF VCT51E CT12000200
CX24 4822 124 41543 ELECT. 1µF 50V RA-2 OA10505020
CX25 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CX93
JUMPER 75060501P0
CX96
CX97 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CX98 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CX99 /U 4822 126 10362 CER. 22pF ±5% DA15220110
CZ01
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ05
CZ06
4822 124 11947 ELECT. BP 10µF 16V EQ10601630
CZ10
CZ11
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ25
CZ26 4822 124 11947 ELECT. BP 10µF 16V EQ10601630
CZ27
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ33
CZ34 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ35
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ42
CZ43 /K,/N,/S 4822 126 10362 CER. 22pF ±5% DA15220110
CZ44 /U 4822 122 33792 CER. 10pF ±5% DA15100120
CZ45 /K,/N,/S 4822 126 11553 CER. 15pF ±5% DA15150120
CZ46 4822 126 11591 CER. 24pF ±5% CH 50V BLK DD15240300
CZ47 4822 126 10362 CER. 22pF ±5% DA15220110
CX48 CER. 1200pF DK16122300
CZ49 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CZ50 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CZ51 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CZ52 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CZ53 JUMPER 75060501P0
CZ54 JUMPER 75060501P0
CZ55
5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ60
CZ61 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ62 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ63 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ65 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CZ66 4822 124 41537 ELECT. 220µF M 6.3V OA22700620
CZ67 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CZ68 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CZ69
4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CZ77
CZ78 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CZ79 4822 122 40617 CER. 0.1µF +80%-20% 50V DC DD38104010
CZ80 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ81 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ82 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ83 4822 124 11947 ELECT. BP 10µF 16V EQ10601630
CZ84 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ85 9965 000 01040 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ86 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ87 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ88 5322 124 21731 ELECT. 10µF M 50V RA-2 OA10605020
CZ89
4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CZ92
CZ93 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CZ94 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
CZ95 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CZ97 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CZ98 4822 122 30043 CER. 0.01µF +80%-20% Z 50V DK18103310
PZ04-CAPACITOR (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
PZ04-RESISTORS
RX11 4822 050 21801 180
Ω
±5% 1/4W GG05181140
RZ06
4822 111 41355 75
Ω
±5% 1/6W GD05750160
RZ15
RZ22 JUMPER 75060501P0
RZ23 JUMPER 75060501P0
CX92
