Marantz sr-18 u - Technical Description

73
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C657 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C658
4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C662
C663 4822 126 13396 CER. 0.047µF ±10% 16V CHIP DK96473200
C664 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C666 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C667 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C668 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C669 4822 126 14417 CER. 0.01µF ± 10% B CHIP DK96103300
C670 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C680 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C691 4822 126 14417 CER. 0.01µF +80%-20% CHIP DK96103300
C692 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C693 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C694 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
C695 4822 126 11687 CER. 0.1µF +80%-20% CHIP DK98104200
C696 5322 126 11583 CER. 0.01µF ± 10% B CHIP DK96103200
C697 5322 126 11583 CER. 0.01µF ± 10% B CHIP DK96103200
P604-CAPACITORS (COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : CE31 CE32 CE41
CH01-CH04 CH13 CH25
CH51-CH54 CH63 CH75
CJ01-CJ04 CJ09 CJ10
CJ51-CJ54 CJ71-CJ74 CK09
CK10 CR19
P604-RESISTORS
RD01 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RD05 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RD07 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RD61
4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RD66
RD92 4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RD94 4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RE01 4822 051 30561 CHIP 560Ω ± 5% 1/16W NN05561610
RE02 4822 051 30101 CHIP 100Ω ± 5% 1/16W NN05101610
RE03 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE04 4822 116 83211 CHIP 1.8kΩ ± 5% 1/16W NN05182610
RE05 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE06 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE07 4822 051 30472 CHIP 4.7kΩ ± 5% 1/16W NN05472610
RE08 4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RE10 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE11 4822 051 30472 CHIP 4.7kΩ ± 5% 1/16W NN05472610
RE12 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE13 4822 051 30151 CHIP 150Ω ± 5% 1/16W NN05151610
RE14 4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RE15
4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE18
RE19 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE20 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE21 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE22 4822 051 30472 CHIP 4.7kΩ ± 5% 1/16W NN05472610
RE23 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE24 4822 051 30332 CHIP 3.3kΩ ± 5% 1/16W NN05332610
RE25 4822 051 30822 CHIP 8.2kΩ ± 5% 1/16W NN05822610
RE31 4822 051 30392 CHIP 3.9kΩ ± 5% 1/16W NN05392610
RE32 4822 051 30472 CHIP 4.7kΩ ± 5% 1/16W NN05472610
RE33 4822 051 30104 CHIP 100kΩ ± 5% 1/16W NN05104610
RE34 4822 051 30223 CHIP 22kΩ ± 5% 1/16W NN05223610
RE35 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE41 4822 051 30223 CHIP 22kΩ ± 5% 1/16W NN05223610
RE42 4822 051 30683 CHIP 68kΩ ± 5% 1/16W NN05683610
RE43 4822 116 83206 CHIP 120Ω ± 5% 1/16W NN05121610
RE44 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RE45 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE46 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE47 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RE48 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RE49 4822 051 30473 CHIP 47kΩ ± 5% 1/16W NN05473610
RE50 4822 117 12139 CHIP 22Ω ± 5% 1/16W NN05220610
RE61 4822 051 30104 CHIP 100kΩ ±5% 1/16W NN05104610
RE62 4822 051 30102 CHIP 1kΩ ± 5% 1/16W NN05102610
RE63 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE64 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RE65 4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RE67 4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RE68 4822 116 82487 CHIP 0Ω ± 5% 1/16W NN05000610
RH01
4822 116 83211 CHIP 1.8kΩ ± 5% 1/16W NN05182610
RH12
RH13
4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH19
RH21 4822 051 30152 CHIP 1.5kΩ ±5% 1/16W NN05152610
RH22 4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH23 4822 116 83208 CHIP 12kΩ ±5% 1/16W NN05123610
RH24 4822 051 30101 CHIP 100Ω ± 5% 1/16W NN05101610
RH25 4822 051 30104 CHIP 100kΩ ± 5% 1/16W NN05104610
RH26
4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH32
RH34 4822 051 30152 CHIP 1.5kΩ ±5% 1/16W NN05152610
RH35 4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH36 4822 116 83208 CHIP 12kΩ ±5% 1/16W NN05123610
RH37 4822 051 30101 CHIP 100Ω ± 5% 1/16W NN05101610
RH38 4822 051 30104 CHIP 100kΩ ± 5% 1/16W NN05104610
RH39 4822 051 30222 CHIP 2.2kΩ ±5% 1/16W NN05222610
RH40 4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH41 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
RH42 4822 051 30105 CHIP 1MΩ ± 5% 1/16W NN05105610
RH51
4822 116 83211 CHIP 1.8kΩ ± 5% 1/16W NN05182610
RH62
RH63
4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH69
RH72 4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH73 4822 116 83208 CHIP 12kΩ ±5% 1/16W NN05123610
RH74 4822 051 30101 CHIP 100Ω ± 5% 1/16W NN05101610
RH75 4822 051 30104 CHIP 100kΩ ± 5% 1/16W NN05104610
RH76
4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH82
RH85 4822 051 30472 CHIP 4.7kΩ ± 5% 1/16W NN05472610
RH86 4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RH87 4822 051 30101 CHIP 100Ω ± 5% 1/16W NN05101610
RH88 4822 051 30104 CHIP 100kΩ ± 5% 1/16W NN05104610
RJ01
4822 116 83211 CHIP 1.8kΩ ± 5% 1/16W NN05182610
RJ12
RJ13
4822 051 30222 CHIP 2.2kΩ ± 5% 1/16W NN05222610
RJ16
RJ17 4822 051 30472 CHIP 4.7kΩ ± 5% 1/16W NN05472610
RJ18 4822 051 30472 CHIP 4.7kΩ ± 5% 1/16W NN05472610
RJ19 4822 116 83215 CHIP 5.6kΩ ± 5% 1/16W NN05562610
RJ20 4822 116 83215 CHIP 5.6kΩ ±5% 1/16W NN05562610
RJ21 4822 051 30101 CHIP 100Ω ± 5% 1/16W NN05101610
RJ22 4822 051 30101 CHIP 100Ω ± 5% 1/16W NN05101610
RJ23 4822 051 30104 CHIP 100kΩ ± 5% 1/16W NN05104610
RJ24 4822 051 30104 CHIP 100kΩ ± 5% 1/16W NN05104610
RJ25 4822 051 30103 CHIP 10kΩ ±5% 1/6W NN05103610
RJ26 4822 051 30103 CHIP 10kΩ ± 5% 1/16W NN05103610
