Marantz sr-18 u - Page 59

85
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
(VERS. :VERSION, U:U.S.A., F:JAPAN, K:FAR EAST,
**
:EUROPE)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CZ06
4822 124 23112 ELECT 10µF 16V EQ10601630
CZ10
CZ11
4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ25
CZ26 4822 124 23112 ELECT 10µF 16V EQ10601630
CZ27
4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ33
CZ34 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ35
4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ42
CZ43 K KS 4822 126 10362 CER. 22pF ±5% DA15220110
CZ44 U 4822 122 33792 CER. 10pF ±5% DA15100120
CZ45 K KS 4822 126 11553 CER. 15pF ±5% DA15150120
CZ46 4822 126 11591 CER. 24pF ±5% CH 50V BLK DD15240300
CZ47 4822 126 10362 CER. 22pF ±5% DA15220110
CZ49 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CZ50 4822 122 40617 CER. 0.1µF +80%-20% 50V DD38104010
CZ51 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CZ52 4822 124 41543 ELECT. 1µF M 50V RA-2 OA10505020
CZ53 JUMPER 75060501P0
CZ54 JUMPER 75060501P0
CZ55
4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ60
CZ61 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ62 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ63 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ65 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CZ66 4822 124 41537 ELECT. 220µF M 6.3V OA22700620
CZ67 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CZ68 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CZ69
4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CZ77
CZ78 4822 124 41537 ELECT. 220µF M 6.3V RA-2 OA22700620
CZ79 4822 122 40617 CER. 0.1µF +80 -20% DD38104010
CZ80 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ81 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ82 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ83 4822 124 23112 ELECT 10µF 16V EQ10601630
CZ84 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ85 4822 124 41544 ELECT. 470µF M 6.3V RA-2 OA47700620
CZ86 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ87 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ88 4822 124 22571 ELECT. 10µF M 50V RA-2 OA10605020
CZ89
4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CZ92
CZ93 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CZ94 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
CZ95 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CZ97 4822 124 90353 ELECT. 100µF M 10V RA-2 OA10701020
CZ98 4822 122 30043 CER. 0.01µF +80%-20% 50V DK18103310
PZ04-CAPACITORS (COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CX21 CX92 CZ48
PZ04-RESISTORS
RX11 4822 050 21801 180Ω ± 5% 1/4W GG05181140
RZ06
4822 111 41355 75Ω ± 5% 1/6W GD05750160
RZ15
RZ22 JUMPER 75060501P0
RZ23 JUMPER 75060501P0
RZ24
4822 111 41355 75Ω ± 5% 1/6W GD05750160
RZ29
RZ36
JUMPER 75060501P0
RZ41
PZ04-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RX01-RX10
RX12-RX22 RX24-EX29
RZ01-RZ05 RZ16-RZ20
RZ30-RZ32 RZ34 RZ35
RZ42-RZ48 RZ50 RZ51 RZ53
RZ54 RZ56-RZ60 RZ67
PZ04-SEMICONDUCTORS
DX01 4822 130 80321 ZENER DIODE 10V HD31001000
DZ01
4822 130 32362 DIODE 1SS176 MA165 1SS254 HD20002000
DZ03 30V 0.1A
DZ05 4822 130 32362 DIODE 1SS176 MA165 1SS254
30V 0.1A
HD20002000
DZ19 ZENER DIODE MTZ 2.7B 2.7V HD30271000
QX01
4822 130 41947 TRS. 2SC536SP 2SC2458 HT30001000
QX04 2SC3311 2SC1740S
QX05 K KS 4822 130 63211 DIG.TRS. DTA114TS UN4115
10K
BA10004000
QX07 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
QZ01 IC MM1140XF HC10083550
QZ02 IC BA7612N HC10201210
QZ03 IC MM1140XF HC10083550
QZ04 IC BA7612N HC10201210
QZ05 IC BA7649A G-1 VIDEO SW HC10179210
QZ06 IC BA7613N HC10202210
QZ07 IC BA7649A G-1 VIDEO SW HC10179210
QZ08 IC BA7612N HC10201210
QZ09 IC NJM2244
3IN SW 75Ω DRIVER
HC10119090
QZ10 IC NJM2263D HC10198090
QZ11 IC OSD LC74781 HC10377030
QZ12 K KS 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QZ13 K KS 4822 130 61189 DIG.TRS. DTC114TS UN4215
10K
BA20004000
QZ14 K KS 4822 130 61189 DIG.TRS. DTC114TS UN4215
10K
BA20004000
QZ16 IC BA7613N HC10202210
QZ17 IC BA7613N HC10202210
QZ18 IC BA7613N HC10202210
QZ19 IC NJM2244
3IN SW 75Ω DRIVER
HC10119090
QZ20 IC NJM2263D HC10198090
QZ21 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
QZ22 IC 74HC4051 HC705100B0
QZ23 4822 209 83088 IC NJM2903D DUAL COMPA. HC10022090
QZ24 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QZ25 4822 130 61227 DIG.TRS. DTA114ES UN4111
10K 10K
BA10001000
QZ26 4822 130 41947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QZ27 4822 130 60588 DIG.TRS. DTC114ES UN4211
10K 10K
BA20001000
QZ28 IC 74HC32 DIP HC703200B0
QZ29 IC TC74HC132AP HC713205D0
