Marantz SR5011 - Level Diagram

FRONT ch
LEVEL DIAGRAM
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
+20dB
+10dB
0dB
-20dB
-30dB
-40dB
-10dB
LINE IN
-10dBFS
0dBFS=1.06Vrms
-20dBFS
-30dBFS
-40dBFS
A/D IN
71mVrms
(-23.5dBFS)
0dBFS = +/-4.0Vpp=2.83Vrms
PCM9211
H/POUT
75.2mVrms
AVR-S920W/X2300W
SR5011,NR1607
LEVEL DIAGRAM
FRONT ch
-9dB
-
2.5dB
-35dB
200mV
+30dB
SP OUT
4.23Vrms/8Ω
+
29dB
-2.5+3.5=+1.0dB
MAX SIGNAL LEVEL
DOLBY LIMIT LEVEL (ALLch-3dBFS)
GAIN setting of MASTER VOL 00dB
･SW:YES(DIGITAL) -2.5dB =-2.5dB
･SW:YES(ANALOG) -2.5dB+ 3.5dB=+1.0dB
･SW:NONE(DIGITAL) -2.5dB+12dB =+9.5dB
･SW:NONE(ANALOG) -2.5dB+12dB+3.5dB=+13.0dB
①②③
①:Basic OFFSET of VOL=0dB
②:OFFSET of SW NON
③:OFFSET of the AD input
-2.5+12=+9.5dB
-2.5+12+3.5=+13.0dB
-3dB
SW NO
-32dBFS(DIG.IN)
-35.5dBFS(A/D IN)
-20dBFS(DIG.IN)
-23.5dBFS(A/D IN)
＋
＋
LINE IN
H/POUT
＋
SPEAKER
OUT
DSP
ANALOG
ATT
BD34704
GAIN
ADJ.
ZONE2
(AVRX2300,SR5011 ONLY)
PCM1690
D/A
－
－
＋
PLD
PCM9211
A/D
0dBFS
-10dBFS
-20dBFS
-30dBFS
-40dBFS
PCM1690
-3dB
Differential Out
BD34704 MAX.OUTPUT4.2Vrms
42
