Marantz SR6009/U1B - Page 193

VIDEO
11
VIDEO PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D5211 943202500740D DIODE,ZENER(16V/0.5W,SOD-123) CVDMM1Z16H 1
D5256 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D5257 90M-HI200020R INFRAREDL.E.D BVDSIR34ST3F 1
D5312 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
IC511 90M-HC109700R I.C,VIDEOS/W(JRC) CVINJM2595MTE1 1
IC516 963235100630S I.C,VIDEOSW(3IN,1OUT,SSOP-20P) CVINJM2586AVC3 1
IC521 963239008800S I.C,RS232(3.3V) CVIILX3232DT 1
Q5117 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q5211 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q5212 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q5253 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C 1
Q5311 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q5312 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q5313,5314 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 2
Q5315 943214500020S T.R,2SC3052 CVT2SC3052 1
RESISTOR GROUP
R5101-5103 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 3
R5113 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5115 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5117 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5119 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5121 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5151 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5153 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5155 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5157 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5161 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5166 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5169 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5171 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5173 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5175 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5181 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5183 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5185 nsp RES,CHIP(1608/1%/75ohm) CRJ10DF75R0T 1
R5211 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5212 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5231-5234 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 4
R5255 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5256,5257 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R5258 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R5311,5312 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R5313 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
1
R5314 nsp RES,CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R5315 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R5316 nsp RES,CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R5317 nsp RES,CHIP(1608/5%/47ohm) CRJ10DJ470T 1
CAPACIITORS GROUP
C5105,5106 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C5107 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5108 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5109 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5111-5113 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 3
C5121 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5152 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C5154 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C5156 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C5158 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C5160 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C5162 nsp CAP,ELECT(50V/1uF) CCEA1HH1R0T 1
C5163-5165 nsp CAP,CHIP(1608,50V/68pF,C0G)_SAMSUNG CCUS1H680JAS 3
C5166 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5167 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C5168-5170 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C5171 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C5172-5174 nsp CAP,CHIP(1608,50V/68pF,C0G)_SAMSUNG CCUS1H680JAS 3
C5212,5213 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C5214 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C5231 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5233-5235 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 3
C5236 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C5237 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5238,5239 nsp CAP,CHIP(1608,50V/33pF,C0G)_SAMSUNG CCUS1H330JAS 2
C5256,5257 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C5312 nsp CAP,CHIP(2012,10V/4.7uF,Y5V)_SAMSUNG CCUC1A475ZFS
1 *
C5313 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
OTHER PARTS GROUP
BK503 nsp BRACKET,SHIELD CMD1A775 1
BN21B nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
BN27B nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
BN28B nsp PINSOCKET(13P,1.25mm,ANGLE,B-TO-B) CJP13HJ282Z 1
JK511 943643102500M RCAJACK4P(Y/Y/Y/Y),GOLDPLATE CJJ4P084Z 1
JK512 943643102160S JACK,6P(G/G,B/B,R/R),GOLD CJJ4R055Z 1
JK513 943643102510M RCAJACK3P(R/B/G),GOLDPLATE CJJ4S053Z 1
JK521 943646100420S JACK,9PD-SUBFEMALE(RS-232C) CJJ9W001Z 1
JK523 90M-YT004860R JACK,STEREO(BLKMOLD) CJJ2D008Z 1
JK526 90M-YT004860R JACK,STEREO(BLKMOLD) CJJ2D008Z 1
JK531 90M-YT003120R JACK,2P(ORG),SEPA-GND,SILVER CJJ4N036Z 1
RC521 262010007707S SENSOR,REMOTE(36.7KHz)
CRVHM336R 1
