SPK
12
SPK PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D9221-9225 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 5
D9230,9231 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 2
D9233,9234 nsp WIRE,COPPER(D0.6) C3A206 2
D9241-9247 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 7
D9250 943202500720S DIODE,ZENER(3.6V/0.5W,SOD-123) CVDMM1Z3V6H 1
D9303,9304 nsp WIRE,COPPER(D0.6) C3A206 2
D9315-9318 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 4
D9331 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 1
D9333 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 1
D9336 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 1
D9338-9340 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 3
D9343 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 1
D9345 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 1
D9347 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 1
D9349 943203003150S DIODE,RECTIFIER,RADIAL CVD1N4007SRT 1
D9701 943203500500M EOLitemDIODE,BRIDGE.(600V/25A) CVDGBJ2506 1
D9727 943202500870S DIODE,ZENER(3.0V/0.5W,SOD-123) CVDMM1Z3V0H 1 *
D9728 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D9913 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D9914 943202500720S DIODE,ZENER(3.6V/0.5W,SOD-123) CVDMM1Z3V6H 1
IC718 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 1
IC931 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
IC933 943232100370S I.C,REGULATOR(+12V,TO220) CVIKIA7812BPI 1
IC934 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
IC935 00D2631099006
I.C,REGULATOR(-5V,T0220IS) CVIKIA7905PI 1
IC936 943231101930S I.C,REGULATOR(+7V,TO-220IS) CVIKIA7807BPI 1 *
IC937 943231101920S I.C,REGULATOR(-7V,TO-220IS) CVIKIA7907PI 1
Q9221-9225 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 5
Q9230,9231 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 2
RESISTOR GROUP
R7801,7802 nsp RES,M-OXIDEFILM(2W/470ohm) CRG2SANJ471RT 2
R9201-9207 nsp RES,M-OXIDEFILM(1W/10ohm) CRG1SANJ100RT 7
R9211-9217 nsp RES,M-OXIDEFILM(2W/10ohm) CRG2SANJ100RT 7
R9241-9247 nsp RES,CHIP(1608/5%/470Kohm) CRJ10DJ474T 7
R9250 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9251 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9711-9713 nsp RES,M-OXIDEFILM(1W/1Kohm) CRG1SANJ102RT 3
R9727 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9801-9804 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R9806 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9819,9820 nsp RES,CHIP(1608/5%/27Kohm) CRJ10DJ273T 2
R9821,9822 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 2
R9823,9824 nsp RES,CHIP(1608/5%/270ohm) CRJ10DJ271T 2
R9905,9906 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R9907,9908 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 2
R9909 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R9910 nsp RES,CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R9911 nsp RES,CHIP(1608/5%/330Kohm) CRJ10DJ334T 1
R9912 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9913 nsp RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R9914 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9915 nsp RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
1
R9916,9917 943124500350M RES,CEMENT(0.02ohm/3W) CRF3EJR02 2
CAPACIITORS GROUP
C9211-9217 nsp CAP,MYLAR(50V/0.047uF/J) HCQI1H473JZT 7
C9221 nsp CAP,ELECT(50V/100uF) CCEA1HH101T 1
C9250 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C9251 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9301 nsp CAP,ELECT(16V/100uF)-S CCEA1CKS101T 1
C9303 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C9306 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 1
C9309 943134010620S CAP,ELECT(25V/4700uF) CCEA1EH472E 1
C9311,9312 00MOA10801620 CAP,ELECT(16V/1000uF) CCEA1CH102E 2
C9315,9316 nsp CAP,ELECT(50V/10uF)-S CCEA1HKS100T 2
C9317,9318 nsp CAP,ELECT(16V/100uF)-S CCEA1CKS101T 2
C9321,9322 943134010620S CAP,ELECT(25V/4700uF) CCEA1EH472E 2
C9331-9337 nsp CAP,MYLAR(50V/0.1uF/J) HCQI1H104JZT 7
C9531-9539 nsp CAP,MYLAR(50V/0.01uF/J) HCQI1H103JZT 9
C9631-9639 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 9
C9701-9703 90M-OF100490R CAP,METALPEFILM(250V/0.1uF) KCME2E104JP04T 3
C9705,9706
EXPLODED_C34,
C35
963134010180S CAP,ELECT(71V/12000uF),35*58L,NICHICON CCET71VLKS123N 2
C9708 nsp CAP,CHIP(1608,50V/1000pF,X7R)_SAMSUNG CCUS1H102KCS 1
C9727 nsp CAP,ELECT(50V/10uF) CCEA1HH100T 1
C9801-9803 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 3
C9804 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9806 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
C9811 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9905,9906 nsp CAP,ELECT(100V/1uF),85'CBlack CCEA2AH1R0T 2
C9909 nsp CAP,ELECT(100V/1uF),85'CBlack CCEA2AH1R0T 1
C9914 nsp CAP,ELECT(16V/100uF) CCEA1CH101T 1
C9917,9918 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 2
C9919 nsp CAP,CHIP(1608,50V/10pF,C0G)_SAMSUNG CCUS1H100JAS 1
C9920 nsp CAP,CHIP(1608,50V/100pF,C0G)_SAMSUNG CCUS1H101JAS 1
OTHER PARTS GROUP
BD981 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
BK901,902 nsp BRACKET,PCB(FUSE) CMD1A730 2
BK903 nsp PLATE,MAINPCB CMC2A424 1
BN701
EXPLODED_C39
nsp WIREASS'YLOCKING(4P,2.5MM,220MM,UL1569#20,105) CWB7E0042203D 1
BN702
EXPLODED_C40
nsp WIREASS'YLOCKING(5P,2.5MM,220MM,UL1569#20,105) CWB7E0052203D 1
BN703
EXPLODED_C38
nsp WIREASS'YLOCKING(7P,2.5MM,180MM,UL1569#20,105) CWB7E0071803D 1
BN704
EXPLODED_C37
nsp WIREASS'YLOCKING(6P,2.5MM,300MM,UL1569#20,105) CWB7E0063003D 1 *
