Marantz SR6009/U1B - Page 196

CNT
14
CNT PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
Q9001 943229500110S F.E.T,INK0010AC1(N-CH,SC-59,MOSFET,ISAHAYA) CVTINK0010AC1 1
Q9003 943214500020S T.R,2SC3052 CVT2SC3052 1
RESISTOR GROUP
R9006 nsp RES,CHIP(1608/5%/1Mohm) CRJ10DJ105T 1
R9014 nsp RES,CHIP(1608/5%/270Kohm) CRJ10DJ274T 1
R9015 nsp RES,CHIP(1608/5%/8.2Kohm) CRJ10DJ822T 1
R9016 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R9021 nsp RES,CHIP(1608/1%/22Kohm) CRJ10DF2202T 1
R9024 nsp RES,CHIP(1608/1%/6.8Kohm) CRJ10DF6801T 1
R9026 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R9035-9037 nsp RES,CHIP(2012/5%/1Mohm) CRJ18AJ105T 3
CAPACIITORS GROUP
C9006 nsp CAP,CHIP(1608,50V/0.047uF,X7R)_SAMSUNG CCUS1H473KCS 1
C9007 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C9008 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9010 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9016 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9018 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9019 nsp CAP,CHIP(1608,6.3V/4.7uF,X5R)_SAMSUNG CCUS0J475KCS 1
C9024 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9029 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C9701,9702 00D2544577958 CAP,ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 2
OTHER PARTS GROUP
BN25D nsp PINSOCKET(25P,1.25mm,ANGLE,B-TO-B) CJP25HJ282Z 1
BN77D nsp PINSOCKET(19P,1.25mm,ANGLE,B-TO-B) CJP19HJ282Z 1
CN21A nsp PINHEADER(19P,1.25mm,STRAIGHT,B-TO-B) CJP19GI281Z 1
CN21B nsp PINHEADER(19P,1.25mm,STRAIGHT,B-TO-B) CJP19GI281Z 1
CN23A nsp PINHEADER(27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN23C nsp PINHEADER(21P,1.25mm,STRAIGHT,B-TO-B) CJP21GI281Z 1
CN24A nsp PINHEADER(27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN24C nsp PINHEADER(27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN25A nsp PINHEADER(23P,1.25mm,STRAIGHT,B-TO-B) CJP23GI281Z 1
CN26A nsp PINHEADER(09P,1.25mm,STRAIGHT,B-TO-B) CJP09GI281Z 1
CN26C,27 nsp PINHEADER(15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z 2
CN27B nsp PINHEADER(19P,1.25mm,STRAIGHT,B-TO-B) CJP19GI281Z 1
CN28B nsp PINHEADER(13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z 1
CN64C nsp PINHEADER(13P,1.25mm,STRAIGHT,B-TO-B) CJP13GI281Z 1
★
nsp RUBBER,TRANS CHG1A587 1
