SMPS
15
SMPS PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D9001-9006 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 6
D9008,9009 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 2
D9010 00D9430182609 DIODE,SWITCHING CVD1SS133MT 1
D9012 nsp HEATSINKASS'Y(CVDSRL3060P+CMY3A238) CVDSRL3060PBYA 1
┣D9012
943209500030S DIODE,LOWFORWARDSCHOTTKYRECTIFIER CVDSRL3060P 1
┣
D9012
EXPLODED_M18
nsp TRHEATSINK CMY3A238 1
┗D9012
nsp SCREW
CTW3+10JR 1
D9013 00D9630328409 DIODE,RECTIFIER,AXIAL CVD1N4007ST 1
IC901 nsp HEATSINKASS'Y(CVITOP256YN+CMY6A025) CVITOP256YNBZA 1
!
┣
IC901
23901007520AS
I.C,OFFLINEPOWERSWITCH
CVITOP256YN 1
┣IC901
EXPLODED_M17
nsp HEATSINK,TR CMY6A025 1 *
┗IC901
nsp
SCREW CTB3+8JR 1
! IC902 963239010480S I.C,PHOTOCOUPLER CVIPC123Y22FZ0F 1
IC903 212050010508S I.C,SHUNTREGULATOR(TO-92) CVIKIA2431AP 1
ZD908 943202500850S TVSDIODE,120V/5W U CVDP6KE120AT 1
ZD911 943202500860S TVSDIODE,150V/5W CVDP6KE150AT 1
ZD918 963202010440S DIODE,ZENER,1/2W,22V CVDZJ22BT 1
ZD919 00D9600095607 DIODE,ZENER,1/2W,5.6V CVDZJ5.6BT 1
ZD920 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT 1
ZD921 00D9430196306 DIODE,ZENER,1/2W,7.5V U CVDZJ7.5BT 1
ZD921 943202000940S DIODE,ZENER,1/2W,16V N CVDZJ16BT 1
ZD922 00D2760762958 DIODE,ZENER,1/2W,39V CVDZJ39BT 1
RESISTOR GROUP
R9004 nsp RES,CARBON(1/5W,330Kohm,J) CRD20TJ334T 1
R9008,9009 nsp RES,CARBON(1/5W,2.2Mohm,J) U CRD20TJ225T 2
R9010 nsp RES,CARBON(1/5W,1Mohm,J) U CRD20TJ105T 1
R9017 nsp RES,CARBON(1/5W,6.8ohm,J) CRD20TJ6R8T 1
R9018 nsp RES,CARBON(1/5W,56ohm,J) CRD20TJ560T 1
R9019 nsp RES,CARBON(1/5W,3.3Kohm,J) CRD20TJ332T 1
R9020 nsp RES,CARBON(1/5W,5.6Kohm,J) CRD20TJ562T 1
R9027 nsp RES,CARBON(1/5W,4.7Kohm,J) CRD20TJ472T 1
! R9031 943121501000S RES,SURGE,(8.2MOHM,5%,1/2W,PRCTYPE) CRO50TJ825T 1
CAPACIITORS GROUP
! C9001-9003 963132011940S CAP,CERAMIC(X1/Y2,0.01uF,AC250V) CCKDKY103MFM 3
C9004
EXPLODED_C28
943134503040S CAP,ELECT(200V/220uF),105'C U
CCET200NHA221ES
1
C9004
EXPLODED_C28
963134010200S CAP,ELECT(400V/100UF,18X40,NHA) N
CCET400NHA101ES
1
C9009 00D9430175108 CAP,ELECT(50V/10uF),105'C CCEA1HNXA100TS 1
C9012 963132010120S CAP,CERAMIC(DC1KV/1000pF) CCKDDEH102KCM 1
C9017 00MOA47602520 CAP,ELECT(25V/47uF),105'C CCEA1ENXA470TS 1
C9020-9022
EXPLODED_C23-
C25
963134010220S CAP,ELECT(6.3V/5600uF) CCEA0JNXA562ES 3
! C9028 963132011930S CAP,CERAMIC(X1/Y1,2200P,AC250V)
CCKDKX222MEM 1
OTHER PARTS GROUP
BK901,902 nsp BRACKET,PCBM3 CMD1A834 2
BK903 nsp BRACKET,PCB CMD1A629 1
BN903
EXPLODED_C26
nsp WIREASS'YLOCKING(5P,2.5MM,400MM,UL1569#22,105) CWB7D0054003D 1
CN901 nsp WAFER,2P,3.96mm CJP02KA060ZY 1
CN902 nsp WAFER,2P,7.92mm CJP02GA89ZY 1
! CX901,902 943139500020S CAP,POLYPROPYLENEFILM(0.1uF/275VAC) CCQF2E104KZE-T 2
!
CY901,902 963134011730S CAP,CERAMIC(X1/Y1,470P,AC250V) CCKDKX471KBM 2
! F9001 963652010510S FUSE(S506Series,250V,2A) U CBA2C2000TLEC 1
!
F9001
963652010500S FUSE(S506Series,250V,1.6A) N CBA2C1600TLEC 1
! F9002 90M-FS001220R FUSE(218Series,250V/8A)
U KBA2C8000TLEY 1
! F9002 90M-FS001490R
FUSE(218Series,250V/4A) N
KBA2C4000TLEY 1
F9001,9002 nsp HOLDER,FUSE KJCFC5S 2
!
LF901
EXPLODED_C29
943111101290S LINEFILTER(1.2A,29mH) U CLZ9Z176Z 1 4
!
LF901
EXPLODED_C29
943111101300S LINEFILTER(0.7A,65mH) N CLZ9Z177Z 1 4
! RY901 963682010370S RELAY,HL31-1AT-5H,DC5V,1C1P CSL1C006ZE 1
!
T9001
EXPLODED_C27
943102100350S TRANS,SWITCHING CLT9Z093ZE 1
EXPLODED_M19 nsp SHEILD,TRANSCOVER CMC1A445 1
★
nsp TAPE,BOTHSIDE C4FA101 0.02
