Marantz SR6009/U1B - Page 198

F-HDMI
16
F-HDMI PCB ASS'Y
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC541 963236101380P I.C,HDMIBUFFER CVIAD8195ACPZ 1
Q5401 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q5402 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C 1
RESISTOR GROUP
R5401 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R5403 nsp RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R5404 nsp RES,CHIP(1608/5%/22Kohm) CRJ10DJ223T 1
R5405 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R5407 nsp RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R5409 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R5410,5411 nsp RES,CHIP(1608/5%/2Kohm) CRJ10DJ202T 2
RN541-544 nsp RES,CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 4
CAPACIITORS GROUP
C5401-5405 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 5
C5406 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C5407-5411 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 5
C5412 nsp CAP,CHIP(1608,50V/0.01uF,X7R)_SAMSUNG CCUS1H103KCS 1
C5413 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 1
C5414 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
C5420-5423 nsp CAP,CHIP(1608,50V/0.1uF,X7R)_SAMSUNG CCUS1H104KCS 4
C5424 nsp CAP,CHIP(2012,6.3V/10uF,X5R)_SAMSUNG CCUC0J106KCS 1
OTHER PARTS GROUP
CN541 nsp WAFER,FFC,SMD(23P-1mm,STRAIGHT) CJP23GA193ZY 1
JK541 943643103000S JACK,HDMI(TYPE-A,SMT-19P,W/OFLANGE) CJJ9H022Z 1 *
L5401,5402 nsp FERRITECHIPBEAD(1608/60R,CB03YTYH600) CLZ9R005V 2
★
nsp
EARTH,HDMI
CMC2A436 1
