DIGITAL
17
※Parts indicated by "nsp"on this table cannot be supplied.
※
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1101 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T 1
D1102,1103 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 2
D1701 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 1
D1901,1902 201310001503S DIODE,ULTRA-HIGHSPEED CVDKDS160RTKP 2
D3975 00D2760718902 DIODE,SCHOTTKY,30V CVDRB521S-30 1
D4347-4352 943204500380S DIODE,SCHOTTKYBARRIEAR(40V,0.03A,SOD-523) CVDRB751S-40 6 *
IC111-120 943239101070S I.C,DC-DCCONVERTER(3A,QFNT&R-24P) CVIEN5339QI 10
IC121 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC122 943239100730S I.C,SYSTEMRESET(4.8V,SOT-25A) CVIPST8448NR_A 1
IC123 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC151 - I.C,CPU(2M/PLQP0144KA-A) CVIR5F56108VNFP 1
┗IC151
943243102630M
R5F56108VNFP (MAIN CPU for CX870) (U)
U CX870 Model CVIANAM2047AV 1 *
┗IC151
943243102600M R5F56108VNFP (MAIN CPU for CX870) (N) N CX870 Model CVIANAM2048AV 1 *
┗IC151 943243102280M R5F56108VNFP (MAIN CPU for CY920) U CY920 Model CVIANAM2014AV 1 * 2
IC152 943239101500S I.C,EEPROM(128KBIT,SOP-8P)
1
IC171 - I.C,CPU(32BIT,1MFLASH) CVIR5F5210ABDFP 1
┗IC171
943243102860S I.C,SUBCPU(SR6009/U1B) U CVIANAM2015AV
1
*
┗IC171
943243102890S I.C,SUBCPU(SR6009/N)
N CVIANAM2023AV 1 *
IC191 00D2623448908 I.C,3STATEQUADBUFFER CVITC74VHC125FT 1
IC201 943236101350D I.C,DIR/DIT(WITHADC,LQFP-48P) CVIPCM9211PTR 1
IC202 943236101520D I.C,DIR(SSOP-16) CVILC89091JA-H 1
IC203 943239100690S I.C,2CHDAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC204 00D2623077900 I.C,HEXINVERTER HVITC74VHCU04FT 1
IC205 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC221 - IC,PLD(TQFP,100P)
1
┗IC221
943243102870S I.C,APLD(SR6009/U/N/K) CVIANAM2018AV 1 *
IC251 943245100580S I.C,DSP(LQFP-176P/400M)
1 *
IC252 943246101030S I.C,64MDRAM(54P)
1
IC253 - I.C,SERIALFLASH(16M)
1
┗IC253
943248102970S I.C,DSP1(SR6009/U/N/K) CVIANAM2017AV 1 *
IC301 943239101080S I.C,DAC(8CH,HTSSOP-48) CVIPCM1690DCAR 1
IC302-305 943232100380S I.C,DUALOPAMP(SOP-8P) CVINJM8080G 4
IC351 963236101220D I.C,HDMIRX
1
IC381 23681015960AS I.C,HDMI2.0TX+SCALER/ES5 CVIMN8647771 1
IC391 23681015960AS I.C,HDMI2.0TX+SCALER/ES5 CVIMN8647771 1
IC392 943239101510S I.C,MUX/DEMUX(TSSOP-16P)
1
IC401 23681016160AS I.C,VSP(ADV8003KBCZ-8B) CVIAD55/058Z-0 1
IC402,403 24681020160AS I.C,DDR2SDRAM(512Mbits,84-ballFBGA)
2
IC404 - I.C,SERIALFLASH(128M,SOP-16)
1
┗IC404
943248102960S I.C,OSDFLASH(SR6009/U1B)
U CVIANAM2016AV 1 *
┗IC404
943248102980S
I.C,OSDFLASH(SR6009/N) N CVIANAM2024AV 1 *
IC421 - I.C,PLD(FBGA,256P,MAXII)
1
┗IC421
943243102880S I.C,VPLD(SR6009/U/N/K) CVIANAM2019AV 1 *
IC431 23681015960AS I.C,HDMI2.0TX+SCALER/ES5 CVIMN8647771 1
IC501 24681009260AS MX25L25635FMI-10G CY920 Model
1 2
IC502 23671011050AS I.C,IPODAUTHENTICATIONFROMD&M
1
IC503 943239101090S I.C,Highsideswitch(TSSOP-B8) CY920 Model CVIBD82065FVJ-E2 1 2
Q1101 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CY920 Model CVTTPC6111 1 2
Q1102,1103 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 2
Q1105,1106 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 2
Q1111 943216500050S
T.R,RT1N441C(47K-47K)
CY920 Model CVTRT1N441C 1 2
Q1112,1113 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 2
Q1115 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1116 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1117 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1119 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1121 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1122 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1123 00D2710326904 T.R,2SA1954 CVT2SA1954 1
Q1124 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1125 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1126 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1127 943212500220D T.R,2SA2166,PNP,TO-236,ISAHAYA CVT2SA2166 1
Q1128 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1131 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1251 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1252 943229500020S MOSFET,TPC6111(P-CH,U-MOSV) CVTTPC6111 1
Q1701 943214500030S T.R,MUTE CVTINC2001AC1 1
Q1702,1703 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1704 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1706 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1901 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1911 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1921 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1951 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q1952,1953 943214500020S T.R,2SC3052 CVT2SC3052 2
Q1954 963212500030S T.R,ISA1530AC1 CVTISA1530AC1 1
Q1955,1956 943214500020S T.R,2SC3052 CVT2SC3052
2
Q1961 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1971 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1981 943214500020S T.R,2SC3052 CVT2SC3052 1
Q2001 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1
Q3841,3842 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3851,3852 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3861,3862 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3871,3872 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3941,3942 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3951,3952 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3961,3962 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 2
Q3971-3973 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 3
R1002 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R1004 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R1111 nsp RES,CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R1112 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R1113 nsp RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R1114 nsp RES,CHIP(1608/1%/348Kohm) CRJ10DF3483T 1
To Next Page
