Main Display (1 of 2)
HOME
MAIN DISPLAY (1 of 2)
Buttons and Display exposed when the door is
Open (3 of 3)
6
A Light illumination
When the power to this device is switched on, the
surrounding area is lit blue. The settings can be changed so
the light does not switch on.
Volume indicator
Input source indicator
The currently selected input source name is displayed.
If the input source name has been changed using “Source
Rename” in the menu, the input source name after the
change is displayed.
Standard display
Tuner display
These light up according to the reception conditions
when the input source is set to “HD Radio”.
Lights up when the broadcast is properly tuned in.
In the FM mode, this lights up when receiving stereo
broadcasts.
Main display
The input source name, sound mode, setting values and other information are displayed here.
1
2
3
4
5
