SETUP
After all components are connected, initial setup must be performed.
ON SCREEN DISPLAY MENU SYSTEM
The SR9300 incorporates an on-screen menu system, which makes
various operations possible by using the cursor (Up, Down, Left,
Right) and OK buttons on the remote control unit.
Notes:
• To view the on-screen displays, make certain you have made a
connection from the Monitor Out jack (VIDEO, S-VIDEO or
SCART)on the rear panel to the composite,S-Video or
component input of your TV or projector. (see 26 page)
• In order to view the SR9300’s displays, the correct video source
must be selected on the video display.
1.
Select the AMP mode in remote commander.
2.
Press M(menu) button on the remote commander to display the
“MAIN SETUP MENU” of the OSD menu system. There are 8
items in the MAIN SETUP MENU.
3.
Select a desired sub-menu with Up or Down cursor button, and
press the OK button to entry.
The display will change to selected sub-menu.
You can lock the condition of setup to each sub-menu with Left or
Right cursor buttons.
Notes: If you desire to adjust any sub-menu, you need to set
UNLOCKED.
4.
If you desire to exit from this menu system, press Ex(exit) button
or move the cursor to EXIT and press the OK button.
MA I N SE TUP MENU
1 ) I NPUT SETUP : UNLOCKED
2 ) SPEAKER SETUP : UNLOCKED
3 ) PREFERENCE : UNLOCKED
4 ) SURROUND : UNLOCKED
5)PRO LOGIC II :UNLOCKED
6)CS II :UNLOCKED
7)MULTI ROOM :UNLOCKED
8)7.1 CH IN :UNLOCKED
9)DC-TRIG SETUP:UNLOCKED
EX I T
1INPUTSETUP
CD : D6 - AT TV : D4 - AT
TAPE :ANA DSS :D3-AT
CD-R :D1-AT DVD :D5-AT
VCR1 : ANA
VCR2 : ANA
LD : D2 - AT
AUX 1 : D - AT
MA I N EX I T
3 PREFERENCE
TV-AUTO : DISABLE
OSD I NFO : ENABLE
D I G I TAL OUT : SOURCE
SUBWOOFER OUT : THX
MA I N EX I T
4 SURROUND
SURR . MODE : AUTO
C I NEMA RE - EQ : OFF
LFE LEVEL : 0 dB
SURR L /R EFFECT :
∗∗
∗∗
∗
∗∗
∗∗
∗
∗∗
∗∗
∗ dB
SURR BACK EFFECT :
∗∗
∗∗
∗
∗∗
∗∗
∗
∗∗
∗∗
∗ dB
CENTER EFFECT :
∗∗
∗∗
∗
∗∗
∗∗
∗
∗∗
∗∗
∗ dB
SUB W EFFECT :
∗∗
∗∗
∗
∗∗
∗∗
∗
∗∗
∗∗
∗ dB
MA I N EX I T
7MULTI ROOM
MUL T I ROOM : OF F
MUL T I S PKR : OF F
VIDEO : DVD
AUD I O : DVD
VOLUME SETUP : VARI ABLE
VOLUME LEVEL : - 90 dB
SLEEP TIMER : OFF
- - - -MA I N - ROOM STATUS- - - -
V I DEO : DVD AUD I O : DVD
MA I N EX I T
5PLII -MUSIC PARAMETER
PARAMETER : DEFAULT
PANORAMA : OFF
DIMENSION : 4
CENTER WI DTH : 0
MA I N EX I T
9-2 DC TRIGGER SETUP
DC TR I G- 2 : D I SABLE
CD : OFF TV : OFF
TAPE : OFF DSS : OFF
CD- R : OFF DVD : OFF
TUNER: OFF VCR1 : OFF
AUX1 : OFF VCR2 : OFF
AUX2 : OFF LD : OFF
MA I N RETURN EX I T
9-1 DC TRIGGER SETUP
DC TR I G- 1 : D I SABLE
CD : OFF TV : OFF
TAPE : OFF DSS : OFF
CD- R : OFF DVD : OFF
TUNER: OFF VCR1 : OFF
AUX1 : OFF VCR2 : OFF
AUX2 : OFF LD : OFF
MA I N NEX T EX I T
87.1CHINPUTLEVEL
FRONT L : 0 dB
CENTER : 0 dB
FRONT R : 0 dB
SURR . R : 0 dB
SURR . B R : 0 dB
SURR . B L : 0 dB
SURR . L : 0 dB
SUB W : 0 dB
MA I N EX I T
2-1 SPEAKERS SIZE
THX SPKR SYSTEM : YES
SUBWOOFER : YES
FRONT L /R : SMALL
CENTER : SMALL
SURROUND L / R : SMALL
SURR . BACK : 2CH
SURR . BACK S I ZE : SMALL
MA I N NE X T EX I T
2 - 3 SPEAKERS D I STANCE
FRONT L : 10 f t 3. 0 m
FRONT R : 10 f t 3. 0 m
CENTER : 10 f t 3 . 0 m
SURR . L : 10 f t 3 . 0 m
SURR .R : 10 f t 3 . 0 m
SUB W : 10 f t 3 . 0 m
SURR .B L : 10 f t 3 . 0 m
SURR .B R : 10 f t 3 . 0 m
MA I N RETURN NEXT EX I T
2-4 SPEAKERS LEVEL
T EST MODE : MANUAL
FRONT L : 0 dB
CENTER : 0 dB
FRONT R : 0 dB
SURR .R : 0 dB
SURR .B R : 0 dB
SURR .B L : 0 dB
SURR . L : 0 dB
SUB W : 0 dB
MA I N RETURN NEXT EX I T
2 - 5 BASS PEAK LEVEL
BASS PEAK TEST : START
VOLUME LEVEL : + 1 8 dB
--------------------
ENTER
MA I N RE TURN EX I T
2-2 THX AUDIO SETUP
BOUNDARY GA I N COMP
T HX ULTRA2 SUB–W : YES
B.G.C. : ON
ADVANCED SPKR ARRAY
SURR .B SPKR : TOGETHER
MA I N RETURN NEXT EX I T
6CSII PARAMETER
TRUBASS : 0
SRS D I ALOG : 0
MA I N EX I T
