Marantz UD9004/U1B - Page 11

9
UD9004
(2) DisconnecttheconnectorwireandFFCcables,thenremovethescrews.
5. AUDIO XLR UNIT
(1) Remove the screws.
(2) Remove the screws.
J801
J807
J805
JH01
JH02
FFC Cable
v
Proceeding : TOP COVER →
→
→
→
→
SIDE COVER (L) and (R) SUB ASSY
AUDIO SUR/BACK/S_W UNIT AUDIO SUR/CENTER UNIT
AUDIO FRONT L/R UNIT AUDIO XLR UNIT
Direction of photograph: A
v
