Table 2-9. VAR Control Adjustment Ranges *
VAR Control Adjust – LED 6 Blinking Slowly
Maximum Adjustment Range:
−
100% (absorb) to +100%
(generate)
Increment: 1.0%
LED
Minimum Value †
Maximum Value †
12
84
100
11
67
83
10
51
66
9
34
50
8
17
33
7
1
16
6
-16
0
5
-33
-17
4
-49
-34
3
-66
-50
2
-83
-67
1
-100
-84
* VAR/PF control is available only on DVR
®
2000EC.
† Minimum and maximum values may differ from the Table 2-9 values if the
value has been changed in MARATHON-DVR
®
2000E-COMS software.
MARATHON-DVR
®
2000E-COMS software has 0.5 percent resolution
compared to the 1.0 percent resolution of the HMI.
Table 2-10. Power Factor Control Adjustment Ranges *
Power Factor Control Adjust – LED 6 Blinking Slowly
Maximum Adjustment Range: +0.6 (lag) to –0.6 (lead)
Increment: 0.01
LED
Minimum Value †
Maximum Value †
12
0.66
0.60
11
0.73
0.67
10
0.80
0.74
9
0.86
0.81
8
0.93
0.87
7
1.0
0.94
6
-0.94
-0.99
5
-0.87
-0.93
4
-0.80
-0.86
3
-0.74
-0.79
2
-0.67
-0.73
1
-0.60
-0.66
* VAR/PF control is available only on DVR
®
2000EC.
† Minimum and maximum values may differ from the Table 2-10 values if
the value has been changed in MARATHON-DVR
®
2000E-COMS software.
MARATHON-DVR
®
2000E-COMS software has 0.001 resolution compared
to the 0.01 resolution of the HMI.
