Table 2-13. Stability Range Selection Settings
Stability Range Select – LED 9 Blinking Slowly
Adjustment Range per LED: 1
Frame/Poles
LED
Range Selected
12
N/A
11
N/A
10
N/A
9
N/A
Programmable
8
21
1,000/6
7
7
740/6
6
6
1,000/4
5
5
740/4
4
4
570/4
3
3
430/4
2
2
360/4
1
1
* Note: For
280 Frame generators see
Section 8, Set-Up From the Computer.
Table 2-14. Gain Adjustment Ranges
Gain Adjust – LED 10 Blinking Slowly
Maximum Adjustment Range:
0.5 to 4.5 Kg for AVR and 0 to 100 Kg for FCR
When the unit is operating in AVR, PF, and VAR modes, gain adjustments
are made to AVR Kg. When in FCR mode, gain adjustments are made to
FCR Kg. Front Panel increments: AVR Kg = 0.01 FCR Kg = 0.1
LED
Minimum Value *
Maximum Value *
AVR
FCR
AVR
FCR †
12
4.17
11.1
4.50
12
11
3.84
10.1
4.16
11
10
3.50
9.1
3.83
10
9
3.17
8.1
3.49
9
8
2.84
7.1
3.16
8
7
2.50
6.1
2.83
7
6
2.17
5.1
2.49
6
5
1.84
4.1
2.16
5
4
1.50
3.1
1.83
4
3
1.17
2.1
1.49
3
2
0.85
1.1
1.16
2
1
0.5
0
0.84
1
*
Minimum and maximum values may differ from the Table 2-14 values if the gain value has been changed in
MARATHON-DVR
®
2000E-COMS software.
†
MARATHON-DVR
®
2000E-COMS software allows a maximum FCR Kg setting of 1,000 Kg. A Kg setting of 12
or more entered in MARATHON-DVR
®
2000E-COMS software will be reduced to 12 with the fi rst push of the
HMI “DOWN” pushbutton when adjusting FCR Kg via the front panel.
See Section 8 for proper adjustment.
Table 2-15. Fine Voltage Adjust Setting Ranges
Fine Voltage Adjust – LED #11 Blinking Slowly
Maximum Adjustment Range: -15% to +15%
Increment: 0.1V
The adjustment range for Fine Voltage Adjust is based on the fi ne
voltage adjustment band setting. The default adjustment range is
–10% to +10%. See Section 5, MARATHON-DVR
®
2000E-COMS
Software for Windows® OS, Setting Defi nitions, Setting Adjustments
for information about the Fine Voltage Adjustment Band Setting.
for information about the Fine Voltage Adjustment Band Setting.
