Table 2-11. Underfrequency Adjustment Ranges
Underfrequency Adjust – LED 7 Blinking Slowly
Maximum Adjustment Range: 40 to 65 Hz
Increment: 0.1 Hz
LED
Minimum Value
Maximum Value
12
63.0
65.0
11
60.9
62.9
10
58.8
60.8
9
56.7
58.7
8
54.6
56.6
7
52.5
54.5
6
50.5
52.4
5
48.4
50.4
4
46.3
48.3
3
44.2
46.2
2
42.1
44.1
1
40.0
42.0
Table 2-12. Droop Adjustment Ranges
Droop Adjust – LED 8 Blinking Slowly
Adjustment Range: 0 to 10%
Increment: 0.25%
LED
Minimum Value *
Maximum Value *
12
9.25
10.00
11
8.5
9.00
10
7.75
8.25
9
6.75
7.50
8
6.00
6.50
7
5.25
5.75
6
4.25
5.00
5
3.5
4.00
4
2.75
3.25
3
1.75
2.5
2
1
1.5
1
0
0.75
* Minimum and maximum values may differ from the Table 2-12 values if
the value has been changed in MARATHON-DVR
®
2000E-COMS software.
MARATHON-DVR
®
2000E-COMS software has 0.01% resolution compared
to the 0.25 percent resolution of the HMI.
