Series TT01 Digital Cap Torque Testers User’s Guide
Any combination of the above functions may be selected.
If tones are enabled, a tone will sound when the output, storage, and zero functions have occurred.
9.2 Break Settings
Select Break Settings from the Break Detection menu to configure the settings. The display appears as
follows:
9.3 Auto Output Settings
Scroll to Auto Settings in the Break Detection menu and press ENTER to configure the auto output
settings. Any combination may be selected. The display appears as follows:
Arms the break detection function. When enabled, the letter “B” will appear on the
home screen, between the Mode and Unit indicators. Refer to the Home Screen
and Controls section for details.
Note: Break Detection and First / Second Peak mode cannot be enabled
simultaneously.
Refer to the following sub-sections for details.
Automatically stores the peak reading to memory.
Automatically zeroes the display following data transmission and/or storage. A
time delay may be configured in Break Detection Settings. Refer to the next
sub-section for details.
Sets the percentage of full scale at which the break detection function becomes
active. This threshold is provided to ignore peaks that can occur during sample
loading and unloading.
Available settings: 1–90%, in 1% increments until 5%, 5% increments thereafter.
Sets the percentage drop from the peak reading at which the break is detected.
Available settings: 5%–90% in 5% increments.
Sets the time delay before the primary and peak readings are zeroed. Auto zero
can be disabled if required. Refer to the Auto Output Settings sub-section for
details. Available settings: 1–10 sec. in 1 sec. increments, and 10–60 sec. in 5 sec.
increments.
BREAK DETECTION
SETTINGS
Threshold: 5 %
% Drop: 50 %
Auto Zero Delay
5 sec.
BREAK DETECTION
Enabled
+ Break Settings
+ Auto Output
Auto Storage
Auto Zero
To Next Page
