Series TT01 Digital Cap Torque Testers User’s Guide
3 SETUP
3.1 Mechanical Setup
Place the sample between the posts or jaws of the tester, and tighten, using the knob. Always ensure that
the sample is gripped firmly, however, excessive tightening of thin-walled closures may result in sample
deformation, possibly affecting test results. When the sample is secured, gradually exert torque on the
bottle cap by hand.
3.1.1 Sample gripping methods
Three different sample gripping methods are available, as shown below:
Adjustable jaws (optional)
3.1.2 Proper alignment
The center of the bottle cap should be positioned axially with respect to the center of the loading table.
Side loading or off-center loading may produce erroneous readings, and can damage the instrument.
3.1.3 Mounting to a bench
The tester can be mounted to a bench using the four threaded holes on the underside of the base.
3.2 Installing the USB driver
If communicating via USB, install the USB driver available at: www.mark-10.com/downloads
Caution!
Install the USB driver before physically connecting the tester to a PC with the USB cable.
Further instructions for configuring and using the tester’s outputs are provided in the Communications
and Outputs section.
