Series TT01 Digital Cap Torque Testers User’s Guide
13
10.3 Auto Output Settings
Select the output type. Select RS-232/USB and/or Mitutoyo outputs, and select First and/or Second
peaks. The display appears as follows:
11 DATA MEMORY AND STATISTICS
Series TT01 testers have storage capacity of 1,000 data points. Readings may be stored, viewed, and
output to an external device. Individual, or all, data points may be deleted. Statistics are calculated for the
data presently in memory.
Individual data points may be saved to memory by pressing the DATA key, or automatically via the Break
Detection function, whichever is enabled. Refer to the Communications section for details. Once data
storage has been enabled, the data record number 0000 appears below the primary reading in the home
screen. The record number will increment each time DATA is pressed or the automatic data storage
function is activated. When memory is full the message “MEMORY FULL” will be flashed at the bottom of
the display and a double audio tone will be sounded.
To view, edit, and output stored readings and statistics, select Memory from the menu. The display
appears as follows:
AUTO OUTPUT
SETTINGS
RS232/USB Output
Mitutoyo Output
First Peak
Second Peak
MEMORY
View Data
View Statistics
Output Data
Output Statistics
Output Data & Stats
Clear All Data
