52 RefeReNce PReamPlifieR / Quick-Start Guide
enGliSh
3. Connect a source component to the desired N
0
52
Preamplifier input connectors.
• Use the N
0
52 Balanced input connectors numbered 1,
2, or 3 if the source component offers balanced output
connectors.
• Use the N
0
52 Unbalanced input connectors numbered
4, 5, 6 or 7 if the source component does not offer
balanced output connectors.
• Use the N
0
52 Phono input connectors to connect to a
turntable/phono cartridge.
Quick SetuP and liSten
N
0
52 PREAMPLIFIER
PHONO
SOURCE DEVICE
LINE-LEVEL
SOURCE DEVICE
Balanced
Audio Cable
(not supplied)
Use one
or the other
Use one
or the other
Balanced
Audio Cable
(not supplied)
Unbalanced
Audio Cable
(not supplied)
Unbalanced
Audio Cable
(not supplied)
