5802 INTEGRATED AMPLIFIER / OWNER’S MANUAL
SPECIFICATIONS
ANALOG LINE STAGE (№5805 ONLY)
Line Input Impedance: Balanced (XLR): 20kΩ; Single-ended (RCA): 10kΩ
Volume Control: Balanced; voltage mode; digitally-controlled resistor network
Gain: 8.5dB maximum
Output Impedance: 55Ω
Output Overload: >4.5V RMS
Frequency Response: 20Hz to 20kHz, ±0.03dB; <2Hz to 210kHz, +0.1/–3dB (At unity gain volume setting)
Total Harmonic Distortion: <0.01%,1kHz; <0.03%,20 kHz; 2V RMS output (At unity gain volume setting)
Signal-To-Noise Ratio: >96dB (20Hz to 20kHz, A-weighted); >93dB (20Hz to 20kHz, wideband, unweighted)
(Referred to 2V RMS output, unity gain volume setting)
Input Sensitivity: 53mV RMS at line input for 2.83V RMS at speaker output, maximum volume setting
System Gain: 34.5dB, line input to speaker output, maximum volume setting
PHONO STAGE (№5805 ONLY)
Riaa Frequency Response: 20Hz to 20kHz, ±0.3dB
Infrasonic Filter: Selectable; 20Hz, 1st order (6dB/octave)
MOVING-MAGNET MODE
Input Resistance: 47kΩ
Input Capacitance: Selectable; 20, 70, 120, 170pF
Gain: 39dB at 1kHz
Total Harmonic Distortion: <0.01%, 1kHz, 2V RMS output; <0.05%, 20kHz, 2V RMS output
Signal-To-Noise Ratio: >90dB (20Hz to 20kHz A-weighted, referred to 2V RMS output);
>78dB (20Hz to 20kHz, wideband, unweighted, referred to 2V RMS output)
Maximum Input Level: >190mV at 1kHz; >1.6V at 20kHz
