5802 INTEGRATED AMPLIFIER / OWNER’S MANUAL
AMPLIFIER SECTION
Frequency Response: <2Hz to 20kHz, +0/–0.2 dB; <2Hz to 100kHz, +0/–3dB
Signal-To-Noise Ratio: >103dB (20Hz to 20 kHz, A-weighted); >100dB (20Hz to 20 kHz, wideband, unweighted)
Total Harmonic Distortion + Noise: <0.035% at 1kHz, 125W, 8Ω; <0.18% at 20kHz, 125W, 8Ω
Output Power: 125W RMS per channel at 8Ω, 20Hz to 20kHz
Output Impedance: <0.098Ω, 20Hz to 10kHz; <0.11Ω at 20kHz
Damping Factor: >82, 20Hz to 10kHz; >72 at 20kHz (All referred to 8Ω)
GENERAL
Analog Input Connectors
(№5805 Only):
1 pair balanced line-level inputs (XLR); 2 pairs single-ended line-level inputs (RCA); 1 pair single-ended
moving-coil phono inputs (RCA); 1 pair single-ended moving-magnet phono inputs (RCA)
Digital Audio Connectors: 2 optical digital inputs (Toslink); 1 asynchronous USB digital input (USB-B); №5805: 1 coaxial digital
S/PDIF input (RCA); №5802: 2 coaxial digital S/PDIF input (RCA); №5802: 1 balanced digital AES/EBU
input (XLR)
Output Connectors: 1 pair single-ended line-level outputs (RCA); 2 pairs loudspeaker outputs (High-current binding posts with
banana sockets; accept spade lugs with ¼”/6.3mm spacing up to ⅛”/3mm thick)
Control Connectors: 1 RS-232 port (DB9 connector); 1 IR input (⅛”/3.5mm phone jack); 1 programmable 12V DC trigger output
(⅛”/3.5mm phone jack), 100mA maximum; 1 programmable 12V DC trigger input (⅛”/3.5mm phone jack);
1 Ethernet port (RJ-45 connector)
Mains Voltage: 100VAC, 115VAC, or 230VAC, factory set
Power Consumption:
Standby
, “Green” mode: <0.4W;
Standby
, “Power Save” mode: 7W; №5805:
Standby
, “Normal” mode: 70W;
№5802:
Standby
, “Normal” mode: 45W; №5805: Power on, quiescent: 120W;
№5802: Power on, quiescent: 95W; №5805: Power on, both channels at ⅛ rated power: 240W;
№5802: Power on, both channels at ⅛ rated power: 215W; Power on, maximum: 500W
Dimensions/Weight (Unit): Height: 5.72”/145mm; Height without feet: 5.25”/133mm; Width: 17.25”/438mm; Depth: 19.98”/507mm;
Weight (№5805): 62 lbs/28.1kg; Weight (№5802): 61 lbs/27.6kg
Dimensions/Weight (With Packaging): Height: 13.0”/330mm; Width: 24.0”/610mm; Depth: 28.0”/711mm; Weight (№5805): 73 lbs/33.0kg;
Weight (№5802): 72 lbs/32.6kg
SPECIFICATIONS
