5
Operating | Getting Started Quickly
Tapping and Wiping: Working with the Touchscreen
Registering mfx Locomotives
Quick Access to the Locomotive Controller
(„Popup Fahrpult“ has to be enabled first in the System Settings)
Simple Access to the Locomotive and Item List
Dragging and Zooming: Thanks to
the high-resolution Touchscreen,
simple touches are all you need
to operate this device – such as
with a Smartphone or a Tablet.
For example, in order to enlarge
the track diagram, you drag with
the thumb and index finger „away
from each other“.
Pulling up the Locomotive List: The loco-
motive list can be enlarged as required
with the help of the red horizontal bar on its
upper edge. Simply touch the horizontal bar
and pull up. Pulling in the opposite direction
reduces the locomotive list and even hides it
completely.
Calling up Functions: Open the functions
for the locomotive by tapping on the „F“
symbol on the upper end of the control knob
(right image). You switch the functions on/
off by pressing with your finger.
Setup: Place the mfx
locomotive completely
on the track. mfx loco-
motives can be done
on both the main track
and on the programming
track.
Pulling up the Item List: Touch
the green horizontal bar and pull
down: The item list will open as far
as required. Pulling the horizontal
bar up reduces the item list or
hides it completely.
Running the Locomotive: Tap on the locomotive sym-
bol and hold your finger pressed down on it a little.
The spontaneous control will open (left image). You
set the speed with your fingertip on the control knob.
You can also set the speed by „pushing up“ on the
green bar. Close the spontaneous control by tapping
left or right next to it on the screen.
Reading: After several sec-
onds, the CS3 automatically
begins to read the data.
Finished: The newly
entered locomotive appears
outlined in red in the loco-
motive list. A red „m“ on
the edge of the locomotive
list also refers to the new
registration of the mfx
locomotive.
