Page 74 / 86 Technical Notice CSO/CPO V1.1 / 10.14
9 Options
9.1.14.8 Settings table (variable)
This table explains the acronyms used and allows you to select the setting you wish to change.
The settings for the various controllers are provided with the diagrams and user guide CDs sup-
plied with each device.
Refer to the diagrams and the description in the table below (dependent on the options supplied,
only certain parts of this list may apply).
Code Description *Default value if not specified
Temperature settings (one regulator only)
St Temperature set point -
rd Regulator delta -
r1 Minimum set point -
r2 Maximum set point -
c1 Minimum time between successive switch-ons *(180 sec with a compressor, 30 sec with a
pump and 10 sec with a solenoid valve)
A0 Differential between alarms AL and AH *(=2°C, relative to AL or AH)
AL Low Temperature threshold alarm *(=10°C, relative to set point St)
AH High Temperature threshold alarm *(=10°C, relative to set point St)
Ad Low or high temperature alarms delay at start-up *(1,200 seconds)
AdL Low temperature alarm delay at start-up -
AdH High temperature alarm delay at start-up -
/c1 Probe calibration -
/3 ou C17
Refresh time of the sensor -
Temperature settings (more than one regulator).
The number 1 is added to designate the first regulator.
St1 Temperature set point -
rd1 Regulator delta -
r1.1 Minimum set point -
r2.1 Maximum set point -
c1.1 Minimum time between successive switch-ons *(180 sec with a compressor, 30 sec with a
pump and 10 sec with a solenoid valve)
A0.1 Differential between alarms AL and AH *(=2°C, relative to AL.1 or AH.1)
AL.1 Low Temperature threshold alarm *(=10°C, relative to set point St1)
AH.1 High Temperature threshold alarm *(=10°C, relative to set point St1)
Ad.1 Low or high temperature alarms delay at start-up *(1,200 seconds)
AdL1 Low temperature alarm delay at start-up -
AdH1 High temperature alarm delay at start-up -
/c1.1 Probe calibration -
/3.1 ou C17.1
Période de Refresh time of the sensor de la sonde -
Temperature settings (more than one regulator).
The number 2 is added to designate the second regulator.
St2 Temperature set point -
rd2 Regulator delta -
r1.2 Minimum set point -
