Operating Modes
The indicator can operate in dierent modes (MODF), which can be activated in
the menu 6 of settings; some, like counting scale, can be activated using short-
cuts. The operating modes are the following:
0 | Normal Mode
1 | Counting scale mode (accessible also via its own key)
3 | Remote Mode
COUNTING SCALE MODE | MODF-1
The counting scale mode calculates the amount of units of a given product
(e. g.: screws) based on a sample or reference unitary weight. The sample will
consist of a given amount of units, to serve as a basis for calculating how many
units the weight will represent.
This can be done in one of two ways: through sampling the unitary weight, as
described above, or through a product that already has a set unitary weight.
To use the counting scale mode without a product associated, press the
COU
NTING key. The main indicator will show the number of units (n) e the secondary
the current net weight. Place the sample units in the platform and press
EN
TER to insert the number of units there are; then, place the units one wishes to
weigh/count, and press
ENTER again for the indicator to show the total number
of units that are on the platform.
Pressing
SHIFT and ENTER one quickly followed by the other will change the in-
formation on display, which can be edited at any moment through the enter key.
1. Number of units + Weight on the platform
•
ENTER edits the number of units
2. Number of units + Unitary weight of each unit
•
ENTER edits the unitary weight
3. Weight on the platform + Number of units
•
ENTER edits the number of units
4. Weight on the platform + unitary weight
•
ENTER edits the unitary weight
It is possible to print the result of a weighing in counting scale mode, via the
printing key. The result will be as follows:
5
Main: number of pieces
Auxiliary: total weight
6
Main: total weight
Auxiliary: unit weight
n 21
10503
10~503
500
