MARQUES BM1000 - Settings and Programming; WEIGHT PARAMETERS; COMMUNICATIONS PARAMETERS

User Guide | BM1000
EN
11 Nov 2023
Settings and Programming
The settings for the indicator can be accessed via the settings button (seen on
the right) held for two seconds.
WEIGHT PARAMETERS
There are three weight-related adjustable parameters allowed by the indicator:
STABILITY | This refers to the necessary criteria for a weighing to be considered
stable; the expressions of this parameter are two-fold: the reading margin
(in internal divisions) for the weight to be considered stable, and how many
consecutive readings are necessary to establish its stability (12 readings
correspond to approximately 1 second).
DIGITAL FILTER | This refers to the behaviour of the display regarding weight
variations; it can be set to take more or less time to show weight variations
detected on the platform.
ADC FILTER | This interacts closely with the digital filter; it’s connected to the
read performed by the scale itself, whereas the digital filter concerns only the
displaying of that information; the bigger the number of readings, the less
stable the converter will be.
The values for each parameter are set by selecting a digit from 0 to 9; what each
digit represents in the three parameters is detailed below::
Parameter
0 1 2 3 4 5 6 7 8 9
Stability
[*]Read margin (divisions) 8 6 6 3
Nr of Consecutive readings: 4 6 12 18
Digital Filter
ADC Filter 5 6 7 8 9 10 12 15 20 25
COMMUNICATIONS PARAMETERS
It is possible for an indicator to have two communications ports; the comms
parameters are divided into two groups: the settings applicable to communica-
tions in general, having eect over both ports; and the settings specific to how
each port is to behave – these are the same for both ports, but the two can
have dierent setups. Thus, when accessing the PROG-2 menu, there are three
submenus: a) the parameters applying to both ports, b) the parameters specific
to port A, and c) the parameters specific to port B. The map below shows the
distribution of the parameters:
prog-1
[*] Value 9 of the stability criterion
does not establish a specific
value; rather, it allows for the inser-
tion of personalized values for the
number of consecutive readings
[Num024] and the reading mar-
gin [Mar100]
prog-2
