User Guide | BM1000P TOP
EN
12 Nov 2023
AUTOMATATIC PRINTING MODE
When the automatic printing mode is active, in order to print
0 Inactive
1 Active
it's only necessary to place a weight in the platform and press the PRINT key.
The system records and prints a new weighing every time there is a load on the
platform and the weight stabilizes. The cycle ends by pressing the
PRINT button
again with the weight on zero.
COUNTING SCALE SETTINGS
Definition of the minimum requirements for the
0
Sample > Min Weight
1
Sample > 1:1000 Min Weight
2
Accepts any samples, so long
as Weight < Min Weight
performance of sample calculation. In case the
set requirements aren't met, an error message
is displayed.
COMMUNICATION RATE
Measured in units of 100 mS; where each digit
0
No delay in sending weight mes-
sages
1-9
Milliseconds of delay (in hundreds)
in sending weight messages
from 1 to 9 represents a hundred millise-
conds - selecting 5 means 500 milliseconds
of delay.
mtra
RCOM
1
Shared
Parameters
♦ Automatic Printing
♦ Counting Scale Mode Settings
♦ Communication Rate
♦ Quilo Protocol
♦ Weight Messages
2
Channel 1
Parameters
♦ Comms Protocol
♦ Baud Rate
♦ Number of bits
♦ Ticket Width
♦ Ticket Format
♦ Zeros to the Left
♦ Extra Lines at End of Ticket
♦ Communications Format
♦ Request
♦ Internal Points
♦ Data Origin
3
Channel 2
Parameters
To Next Page
