QUILO PROTOCOL
Activates the use of the exclusive quilo protocol, which est
0
Inactive
1
Active
ablishes the communication with some types of devices and applications (e.g.:
remote setup of the indicator from a computer, or the remote access to the
weight).
WEIGHT MESSAGES
Weight messages contain information whuch can be sent by
0
Inactive
1
Active
the device. In this menu it's possible to detemine which types of messages are
allowed to be sent, regardless of the configurations of each communication
channel. The indicator lists the message types sequentially, which we can in turn
set as active or inactive:
R
Remote
P
Weight
T
Tare
J
Raw readings of ADC converter
C Counting Scale mode
COMMUNICATION PROTOCOLS
The indicator is prepares to use several communications protocols. The spe-
cifications of each of these are described in the Technical Support Document.
Here is a list of the protocols each value refers to.
E, 11, 12 DSD (BM)
0, 1, 2
BM A MOBBA 10 BERKEL-CASIO
3, 4, 5
TISA B METTLER 13 STAR, DIALOG60
6, 7
[Ticket] C GRAVITON 14 RAFELS
8, 9 EPELSA D MOBBA Mini SP 18 DCPC
BAUD RATE
bits/s bits/s
12
1200 192 19200
24
2400 384 38400
48
4800 576 57600
96 9600 115 115200
qilo
BAU
PAUT
Frm
