MARQUES BM1000 - Communication Configuration; NUMBER OF BITS; PARITY; TICKET WIDTH

User Guide | BM1000P TOP
EN
14 Nov 2023
NUMBER OF BITS
The 7-bit mode automatically places two stop bits; 8 bits corres-
0
7 bits
1
8 bits
pond to one stop bit.
PARITY
0
No parity
1
Odd
2
Even
TICKET WIDTH
0
32 column ticket
1
40 column ticket
2
40 column ticket, double width
PRINTER
0
Printer
1
Small label maker format 1
2
Small label maker format 2
3
Big label maker format 1
4
Big label maker format 2
5
Format preset on the label maker
LABEL FORMAT
When 5 is selected in the previous section, there is a need to insert a name for
the preset label format.
ZEROS TO THE LEFT
Option to complete the weight value with spaces or zeros to
0
Inactive
1
Active
the left of the value; parameter which becomes relevant in some protocols like
Mobba, Mettler, etc.
EXTRA LINES AT THE BOTTOM OF THE TICKET
In digits, it sets how many extra lines should the ticket have in order to facilitate
the cut from the roll.
BITS
par
aIMP
PRN
pRn
0s-
CRLF
