SOLO-NX
USER MANUAL
Page 23
8.9 TIMER-TIMED CONTROLED OUTPUT
SOLO-NX unit features 2 timers that can be used to control the ouputs on the unit. Timers can run
in day or week mode depending on the selected setting. For each timer user can select which output
it will control. The behavior of the outputs (Time pulse or Latching mode) is defined in the Output
tab.
The described settings are the same for both timers.
Figure 14: WEB Server-Timer setting →Day mode.
Figure 15: WEB Server-Timer setting →Week mode.
