Martin Audio WAVEFRONT COMPACT - APPLICATIONS GUIDE User Manual

Double W8 column
Here is a 2 wide, 4 deep column of Wavefront W8s.
Vertical coverage of a W8 cluster = the vertical coverage of a single W8 (30º) +
the sum of all the vertical splay angles
For a 4-deep W8 cluster with 20º vertical splay angles = 30º+20º+20º+20º = 90º
Horizontal coverage of a W8 cluster = the horizontal coverage of a single W8
(55º) + the sum of all the horizontal splay angles
For a 2-wide W8 cluster with 30º horizontal splay angles = 55º+30º = 85º
All material © 2007. Martin Audio Ltd. Subject to change without notice.
