Wide coverage cluster
4 or 6 wide, 4 deep W8 clusters may be rigged for very wide coverage. Coverage may
be calculated as follows:
6 wide cluster
6 wide, 4 deep plan view
The horizontal coverage now extends to:
55º+30º+30º+30º+30º+30º = 205º for 30º horizontal splays
and the vertical coverage extends to:
30º+20º+20º+20º = 90º for 20º vertical splays
Circular cluster
Two 6-wide, 4 deep W8 clusters with 30º horizontal splay angles and 20º vertical
splay angles may be flown back-to-back to provide full 360º horizontal x 90º vertical
coverage for, for example, ice shows.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
