Martin Audio WAVEFRONT COMPACT - APPLICATIONS GUIDE User Manual

A2.3Pin-outs and cabling
W8S
EP8 NL8 W8S
1 -1 18" Driver -
2 +1 18" Driver +
3 -2 18" Driver -
4 +2 18" Driver +
5 -3 15" Driver -
6 +3 15" Driver +
7 -4 15" Driver -
8 +4 15" Driver +
(See Section A1.3 for NL connector pin-out drawing)
A2.3.1 Cable and panel connector part numbers
Please note the following part numbers when ordering loudspeaker connectors to
make up cables and patch panels:
Neutrik NL connectors
NL8FC 8 pole cable (female)
NL8MPR 8 pole panel (male)
NL8MM 8 pole inline coupler (male-male)
Cannon EP connectors
EP8-11 8 pin cable female
EP8-12 8 pin cable male
EP8-13 8 pin panel mount female
EP8-14 8 pin panel mount male
Connectors should be kept in good, clean, uncorroded condition to ensure full,
undistorted loudspeaker performance. Corroded or damaged pins and sockets can
cause severe distortion or loss of signal.
All material © 2007. Martin Audio Ltd. Subject to change without notice.
