Martin M2PC - Separate Front Panel from Housing; Remove Cable Adapter PCB

www.martin.com • Olof Palmes Allé 18 • DK-8200 Aarhus N • Denmark
Tel. (+45) 8740 0000 • Fax (+45) 8740 0010
3. Remove the front panel from the
bottom housing, and place it
behind the bottom housing as
shown in the picture.
4. Remove the cable adapter PCB
from the front panel PCB by
pulling it out of its sockets. Don’t
unplug the cabling.
