DMX protocol
Applicable when running MAC Quantum Profile firmware version 1.0.0.
Basic
16-bit
Mode
16-bit
Extended
Mode
DMX Value Function
Fade
type
Default
value
11
0 - 19
20 - 49
50 - 200
201 - 210
211 - 255
Strobe/shutter effect
Shutter closed
Shutter open
Strobe, slow → fast
Shutter open
Random strobe, slow → fast
Snap 30
22
0 - 255
Dimmer fade (MSB)
Closed → open
Fade 0
3
0 - 65535
Dimmer fade (LSB)
Closed → open
Fade 0
34
0 - 255
Cyan
0 → 100%
Fade 0
45
0 - 255
Magenta
0 → 100%
Fade 0
56
0 - 255
Yellow
0 → 100%
Fade 0
67
0
1 - 14
15
16 - 29
30
31 - 44
45
46 - 59
60
61 - 74
75
76 - 89
90
91 - 104
105 - 160
161 - 163
164 - 166
167 - 169
170 - 172
173 - 175
176 - 178
179 - 192
193 - 214
215 - 221
222 - 243
244 - 247
248 - 251
252 - 255
Color wheel
Continuous Scroll (split colors possible)
Open
Open → Slot 1
Slot 1 (Blue)
Slot 1 → Slot 2
Slot 2 (Green)
Slot 2 → Slot 3
Slot 3 (CTC 3200 K)
Slot 3 → Slot 4
Slot 4 (Magenta)
Slot 4 → Slot 5
Slot 5 (Congo Blue)
Slot 5 → Slot 6
Slot 6 (Red)
Slot 6 → Open
Open
Stepped Scroll (snap to full color positions)
Slot 1 (Blue)
Slot 2 (Green)
Slot 3 (CTC 3200 K)
Slot 4 (Magenta)
Slot 5 (Congo Blue)
Slot 6 (Red)
Open
Continuous Rotation
CW, Fast → Slow
Stop (This will stop the color wheel wherever it is at the time)
CCW, Slow → Fast
Random color
Fast
Medium
Slow
Snap 0
Table 1: DMX Protocol
