Martin MAC Quantum Profile User Manual

24 MAC Quantum Profile User Guide
MSB = Most significant byte
LSB = Least significant byte
-25
0 - 255
FX2 selection (see Table 2)
Effect selection (adjust on DMX channel 24)
Snap 0
-26
0 - 126
127 - 128
129-255
FX2 adjustment
Effect reversed fast → slow
Effect stops
Effect slow → fast
Fade 128
-27
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37 - 100
101 - 120
121 - 140
141 - 255
FX synchronization
No sync
Offset shift 10°
Offset shift 20°
Offset shift 30°
Offset shift 40°
Offset shift 50°
Offset shift 60°
Offset shift 70°
Offset shift 80°
Offset shift 90°
Offset shift 100°
Offset shift 110°
Offset shift 120°
Offset shift 130°
Offset shift 140°
Offset shift 150°
Offset shift 160°
Offset shift 170°
Offset shift 180°
Offset shift 190°
Offset shift 200°
Offset shift 210°
Offset shift 220°
Offset shift 230°
Offset shift 240°
Offset shift 250°
Offset shift 260°
Offset shift 270°
Offset shift 280°
Offset shift 290°
Offset shift 300°
Offset shift 310°
Offset shift 320°
Offset shift 330°
Offset shift 340°
Offset shift 350°
Synchronized
Reserved
Random start (FX 1 adjust controls overall speed)
Random duration
Reserved
Snap 0
Basic
16-bit
Mode
16-bit
Extended
Mode
DMX Value Function
Fade
type
Default
value
Table 1: DMX Protocol
