28 MAC Quantum Profile User Guide
INFORMATION
POWER ON TIME
TOTAL 0 ... XXX HR
Display hours fixture has been powered on
since manufacture (not user-resettable)
RESETTABLE
CLEAR
COUNTER?
YES/NO
Display hours fixture has been powered on
since last counter reset (user-resettable)
POWER ON
CYCLES
TOTAL 0 ... XXX HR
Display number of times fixture has been
powered on since manufacture
(not user-resettable)
RESETTABLE
CLEAR
COUNTER?
YES/NO
Display number of times fixture has been
powered on since last counter reset
(user-resettable)
SW VERSION* XX.XX.XX Displays currently active software version
RDM UID* 4D50.XXXXXXXX Displays fixture’s unique RDM ID
FAN SPEEDS*
HEAD FAN 1 ...
BASE FAN 3
0 - XXX RPM
Scroll to displays current speed of each
cooling fan (head and base)
TEMPERA-
TURES*
EFFECT ... DCDC
PCB
X C Displays temperature in °C of all PCBs
DMX LIVE*
RATE 0 - 44 HZ
DMX transmission speed in packets per
second
QUALITY 0 - 100% Percent of packets received
START CODE 0 - 255 Value of the DMX start code
STROBE ... FX
SYNC
XXX
Scroll to see values received on each
DMX channel
TEST*
TEST ALL
Run test sequence of all functions
To test a specific function, se Up/Down
buttons to scroll through functions and
pause. Press Enter to restart test
sequence.
Press Menu button to exit test
TEST LEDS
Run test sequence of LEDs only.
To test a specific LED group, use
Up/Down buttons to scroll through groups
and pause. Press Enter to restart test
sequence.
Press Menu button to exit test
TEST EFFECTS CYAN ... FOCUS
Run test sequence of each effect. Press
Menu button to stop test
TEST PAN/TILT
PAN
Run test sequence of pan functions. Press
Menu button to stop test
TILT
Run test sequence of tilt functions. Press
Menu button to stop test
MANUAL
CONTROL*
RESET Reset fixture
STROBE ... FX SYNC
Scroll through effects to manually control
an effect
Menu level 1 Menu level 2 Menu level 3 Menu level 4 Notes (Default settings in bold print)
Table 3: Control menus
To Next Page
