Martin maxium & maxium Beamer Operating Instructions
V 2.0
17
1 M1 Monopolar HF output 1
2 M1 Activation indicator for monopolar HF output 1
3 Channel selector button for M1 HF output
4 M2 Monopolar HF output 2
5 M2 Activation indicator for monopolar HF output 2
6 Channel selector button for M2 HF output
7 B1 Bipolar HF output 1
8 B1 Activation indicator for bipolar HF output 1
9 Channel selector button for B1 HF output
10 B2 Bipolar HF output 2
11 B2 Activation indicator for bipolar HF output 2
12 Channel selector button for B2 HF output
13 Neutral electrode connector
14 Neutral electrode status indicator (LED)
15 Display
16 MENU button
17 Rotary switch
18 Backlight ring of rotary switch
19 ON/OFF button (power switch)
20 Connector for dual-pedal footswitch
21 Connector for single-pedal footswitch
22 Serial interface connector
23 CAN bus connector
24 Equipotential bonding connector
25 Power cable connector
26 Loudspeaker
27 Rating plate
28 Beamer interface
Neutral electrode (NE) connector.
Neutral electrode ungrounded (floating)
Equipment classification symbol (CF).
The unit is defibrillation-proof.
Means “ATTENTION!
OBSERVE OPERATING INSTRUCTIONS!
ATTENTION – HIGH-FREQUENCY CURRENTS!
CAUTION – HIGH VOLTAGE!
