Model: MTS200 (1U)
Doc. Ref. no. : m08/om/201
Issue no. : 03
User’s Manual Page 16 of 195 Page 16 of 195
Keypad
Status LED
Power : Red
1 PPS : Red
Event : Red
Watchdog : Red
GPS Locked : Bi Color: Green(GPS LOCK) Red (GPS UNLOCK)
Configuration Modes
Front Keypad
Front panel RS-232 DB9 serial console port
SSH, Telnet, Webserver, SNMP
Programmable parameters:
Global Time zone correction
12/24 Hrs Format of Time
COM2 serial port setting
COM2 data format selection (NGTS / T-FORMAT / GPZDA / GPGGA)
Duration of Programmable repetitive event generation output via dry
contact (Per Minute or Hour).
Eth0 and ETH1 Network Settings
DST Settings
Manual Time Setting
Default Settings
NTP Settings
Ethernet Services [SSH, NTP, SNMP, HTTP, HTTPS) Settings
Password Protection
KEY
FUNCTION
MENU
For Entering into Configuration mode.
HELP
To Display help about every parameter
configurations.
OK
To save the final Configurations.
ESC
To come back into Run mode.
UP
Scroll between various parameters in ascending
order in main menu and to change parameters
value in submenu.
DOWN
Scroll between various parameters in descending
order in main menu and to change parameters
value in submenu.
LEFT
To select various available options for the particular
parameter in main menu and scroll between various
parameters in submenu.
RIGHT
To select various available options for the particular
parameter in main menu and scroll between various
parameters in submenu.
POWER SUPPLY
AC: 90 to 264 V, 47-63 Hz
DC: 100-300 V
Power Consumption: 15W max.
OPTIONAL
POWER SUPPLY
DC: 18 – 72 V
