Model: MTS200 (1U)
Doc. Ref. no. : - m08/om/201
Issue no.: 03
Page 17 of 195 User’s Manual
PHYSICAL
DIMENSIONS
19” Rack Mountable
Width:482.6 mm (19”)
Depth:241 mm (9.488”)
Height: 1 U – 44 mm (3.46”)
Weight: 2.1 Kg
Ingress Protection: IP20 enclosure
ENVIRONMENT
Temperature
Operating: 0° C to 50° C
Storage: -20° C to +80° C
Humidity
20 - 90%(Non-condensing)
EXTRA MODULES
(OPTIONAL)
RS232-to-RS485 Converter
LINE AMPLIFIER, SURGE ARRESTOR
Time Distribution Rack (TDR-4)
Time Signal Repeater (TSR-4)
Time Display Unit (TDU-64)
Netser (NGTS to NTP Convertor)
TYPE TEST
Isolation
(Withstanding
voltage)
Between primary terminals* and secondary terminals**:
At least 1500 V AC for 1 minute
Between primary terminals* and grounding terminal:
At least 1500 V AC for 1 minute
Between grounding terminal and secondary terminals**:
At least 1500 V AC for 1 minute
Between secondary terminals**:
At least 500 V AC for 1 minute
* Primary terminals indicate power terminals and relay output terminals.
** Secondary terminals indicate Output Ports.
Insulation resistance: 20MΩ or more at 500 V DC between power terminals
and grounding terminal.
Note: No Isolation between IRIGB-TTL and PPS Output
