Masimo Stork - Voltage Dip Immunity; Voltage Interruption Immunity; Radiated RF Immunity

51
Electromagnetic Immunity
Voltage dips
on power
supply input
lines
IEC 61000-4-
11
0% U
T
1
, 0.5
cycle, at 0°,
45°, 90°,
135°, 180°,
225°, 270°,
and 315°;
0% U
T
1
cycle, and
70% U
T
25/30
cycles at 0°
0% U
T
1
, 0.5
cycle, at 0°, 45°,
90°, 135°, 180°,
225°, 270°, and
315°;
0% U
T
1 cycle,
and 70% U
T
25/30 cycles at
0°
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage
Interruptions
on power
supply input
lines
IEC 61000-4-
11
0% U
T
,
250/300
cycle
0% U
T
, 250/300
cycle
Radiated RF
IEC 61000-4-3
10 V/m 10 V/m Performed over 80 MHz to 2.7 GHz
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and
land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted
theoretically with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an
electromagnetic site survey should be considered. If the measured field strength in the location in which
the ME Equipment is used exceeds the applicable RF compliance level above, the ME Equipment should
be observed to verify normal operation. If abnormal performance is observed, additional measures may
be necessary, such as re-orienting or relocating the ME Equipment.
1
U
T
: Rated voltage for the equipment.
