OWNER’S/OPERATOR’S MANUAL 20.0
7. CONTROL AND PARTS FUNCTIONS
7- 5
BRAKE PEDAL
1.Brake pedal
Press the brake pedal to slow or stop the vehicle.
WARNING
Never operate the UTV with a spongy feeling brake pedal. Operating
the UTV with a spongy brake pedal can result in loss of braking. Loss of
braking could cause an accident.
PARKING BRAKE LEVER
The parking brake lever is located at the left side of
the steering wheel. It will help hold the vehicle from
moving while parked. To set the parking brake, pull
the lever back completely. The parking indicator light
will come on if the main switch is on. To release the
parking brake, pull back on the lever, press the
release button, and then push the lever all the way
front. Be sure to fully release the parking brake
before starting out. Failure to do so may result in
poor performance and premature wearing of the
parking brake and V-belt.
1. Release button
2. Parking brake lever
