OWNER’S/OPERATOR’S MANUAL 20.0
7. CONTROL AND PARTS FUNCTIONS
7- 12
Oil System
The oil tank is located on the right side of the vehicle.
To check the oil:
1. Set machine on a level surface.
2. Start the engine and let it idle for 20-30 seconds.
3. Stop the engine, remove dipstick ○
1
and wipe dry with a clean
cloth.
4. Put dipstick into the oil tank (don’t screw in it), remove it and read the
oil level.
5. Remove dipstick and check to see that the oil level is between the full
and add marks ○
2
. Add oil as indicated by the level on the dipstick.
Do not overfill.
CAUTION
Use only SAE 10W/40, SF OIL. Never substitute or mix oil brands.
Serious engine damage and voiding of warranty can result.
