3.2.2 AC Voltage
Range Resolution Accuracy
200m
V
0.1mV
2V 0.001V
( 0.8% of rdg + 3 digits
20V 0.01V
200V 0.1V
600V 1V ( 1.0% of rdg + 3 digits
- Input Impedance: 10M (
- Overload Protection:
200mV range: 250V DC or AC rms, 2V-600V ranges: 600V DC or AC rms.
- Frequency Range: 40 to 400Hz
- Response: Average, calibrated in rms of sine wave.
- Max. Input Voltage: 600V rms AC
3.2.3 DC Current
Range Resolution Accuracy
2.000
A
0.001A
( 2.0% of rdg + 10
digits
10.00
A
0.01A
- Overload Protection: unfused.
- Max. Input Current:: 10A
- voltage drop 2A range: 20mV,
10A range: 200mV
3.2.4 AC Current
Range Resolutio
n
Accuracy
2.000
A
0.001A ( 3.0% of rdg + 10 digits
10.00
A
0.01A
- Overload Protection: unfused.
- Max. Input Current:: 10A
- Frequency Range: 40 to 400Hz
- Response: Average, calibrated in rms of sine wave.
- voltage drop 2A range: 20mV,
10A range: 200mV
3.2.5 DC Current with clamp, optional
Range Resolut
ion
Accuracy
mete
r 200A
0.1mV
/0.1A
( 1.2 % of rdg + 3
digits
(DC)
Cla
0
to 200A
0.1A
/0.1mV
Typical ( 2.0 %
