Mastech ms6231 - DESCRIPTION; Component Identification; Switch, Buttons and Input Jack Elucidation

- This meter is a portable professional measuring instrument with handsome LCD and back light easily
reading.
- Single operation of a transform switch makes measurement convenient. Overload protection and low
battery indication are provided, this meter is ideal for use in the fields, workshop, school, hobby and
home applications.
- This meter has function of auto range and manual range.
- This meter has function of auto warning.
- This meter has function of auto power off.
- This meter is with the functions of data hold and maximum value hold.
- When using, it can show ranges engineering unit enunciators measuring results.
2.1 NAMES OF COMPONENTS
⑴ LCD Display
⑵ ON/OFF Button
⑶ RANGE Button
⑷ FUNC. Button
⑸ Transform Switch
⑹ 10A Jack
⑺ INPUT Jack
⑻ COM Jack
⑼ Panel
⑽ Button
⑾ DATA-H Button
⑿ MAX.H Button
2.2 SWITCH, BUTTONS AND INPUT JACK ELUCIDATION
( ON/OFF Button
This Button is used to the switch of power.
